Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox 30 Silver TK
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Grizzly 29" alu, 1.5" tapered HT, PF 41x92mm, seatpost diam.27.2mm, HDM Front Derailleur, bottom pull, PM 160mm, QR141mm BOOST dropout , internal cable routing inside DT
Suspension Fork
Rock Shox 30 Silver TK 29" SoloAir 100mm w/PopLoc Remote, 1.5" Alu HT, 9mm QR, 30mm stanchions, magnesium lowers, PM 160mm
Drivetrain
Rear Derailleur
Shimano Deore RD-M6000-GS 10sp
Front Derailleur
Shimano Deore FD-M6020-D HDM
Shift Levers
Shimano Deore SL- M6000 2x10sp
Cassette
Shimano CS-HG500-10, 11-42T
Crank
Shimano FC-M6000-B2, 36/26T
Bottom Bracket
Shimano BB-MT500-PA
Chain
Kmc X10 EPT finish
Wheels
Front Hub
Formula CL-25
Rear Hub
Formula CL-2641
Tires
Kenda Honey Badger XC Sport 29x2.2
Brakes
Brakes
Shimano BR-M396
Disk Rotors
Shimano SM-RT30 180mm & 160mm
Cockpit
Stem
Tec Obvius 3D forged alloy 6061
Handlebar
Tec Obvius flat alloy
Headset
Fsa Orbit 1.5E ZS #57E
Seat
Saddle
Tec
Seatpost
Tec Obvius, alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.532 mm | 1.49 mm | 1.435 mm | 1.402 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 647 mm | 667 mm | 692 mm | 713 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 86 mm | 86 mm | 86 mm | 86 mm |
| Stack | 596 mm | 605 mm | 614 mm | 624 mm |
| Reach | 389 mm | 406 mm | 428 mm | 445 mm |
| Top Tube Length | 570 mm | 590 mm | 615 mm | 635 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 429 mm | 429 mm | 429 mm | 429 mm |
| Wheelbase | 1069 mm | 1089 mm | 1114 mm | 1135 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Grizzly 9.3 completes the Bianchi Grizzly model. Bianchi released 3 bikes variations of this model so far.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1400$. Comparing the average cost of a Crosscountry bike to this one, you will see that Grizzly 9.3 price is 36.07% lower.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Grizzly 9.3 components
Fork
The Grizzly 9.3 comes factory-installed with the RockShox 30 Silver TK fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Fork material
When it comes to the fork, this bike has an aluminum one, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
When leaving the production line, the Grizzly 9.3 model has 29″ wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Bianchi Grizzly 9.3 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Bianchi Grizzly 9.3 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
