Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 800 -
Suspension Rigid -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
IMPULSO gravel ALU 1"1/8 aheaset,seat post 31.6mm, thru axle 12x142mm, flat mount disc version, PF41, compatible with 40mm tire and mudguard and rear carrier predisposition. sizes 47-50-53-55-57-59-61-63cm
Suspension Fork
Full Carbon 1"1/8, flat mount, disc brake, thru axle 12x100mm
Drivetrain
Rear Derailleur
Shimano GRX
Front Derailleur
Shimano GRX
Shift Levers
Shimano GRX Hydraulic disc brake, for 160mm rotor
Crank
Shimano GRX, 46-30T Crank Length: 170mm-XS-S, 172.5mm-M-L, 175mm-XL
Bottom Bracket
Shimano SM-BB71-41B, press fit for road, bearing, inner cover
Chain
Shimano CN-M6100
Wheels
Front Hub
Formula CL-712 road disc, alloy 32h, center lock, thru axle 12x100mm, 2SB bearing
Rear Hub
Formula road disc, center lock, thru axle 12x142mm, 4SB bearing for Shimano
Rims
Velomann disc 700c 622-21, profile 24mm, sleeve join, 32hole, tubeless ready
Tires
Kenda Alluvium 700x40, 60TPI
Brakes
Brakes
Shimano flat mount hydraulic disc brake, included in the shifter
Cockpit
Stem
Velomann, Alloy 6061, raise +/ - 7°, height 38mm, Oversize, 1 1/8", Ext: 70mm-47cm, 90mm-50/53cm, 100mm-55cm, 110mm-57/59cm, 120mm-61/63cm
Handlebar
Velomann Aluminum 6061, reach 70mm, flare angle 16°, drop cc 120 x size 40cm and 130mm x size 42-44-46cm, size: 40cm 47/50/53 - 42cm 55/57/59 - 44cm 61/63
Headset
Fsa NO.8B/ZS4D 1-1/8"
Seat
Saddle
Velomann, lenght/wide 278x144mm
Seatpost
Velomann Alloy shaft AL6061, alloy head, 15mm offset, 31,6mm, Length: 350mm-47/63cm
