Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork RockShox Judy
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Magma 29 alu, 1.1/8" HT, BSA 68mm, seatpost diam. 27,2mm, HDM bottom pull or Side-Swing, PM 160mm, BOOST 9x141mm QR, internal cable routing, sizes 15-17-19-21"
Suspension Fork
Rock Shox Judy TK 29" 100mm w/Remote Lockout,1,1/8" steel HT, alloy crown, coil spring w/pre-load adjust, steel 30mm stanchions, magnesium lowers w/PM 160mm disc mount, 9mm QR
Drivetrain
Rear Derailleur
FH-MT200-B for Center Lock, 32h 141mm OLD BOOST
Front Derailleur
Formula CL-1420 for Center Lock, 32h 100mm OLD, loose balls, axle length 108mm, w/QR
Shift Levers
Deore SL-M5100-R 1x11, clamp band
Crank
Shimano FC-M5100-1, 32T, crank length: 170mm-15", 175mm-17/21"
Bottom Bracket
included in the crankset
Chain
Kmc X11 EPT finish, 11sp
Wheels
Front Hub
Formula CL-1420 for Center Lock, 32h 100mm OLD, loose balls, axle length 108mm, w/QR
Rear Hub
FH-MT200-B for Center Lock, 32h 141mm OLD BOOST
Rims
VelomannDP2.5, 622x25c, pin joint, 32h, anodized, no eyelet, Presta valve hole
Tires
Kenda Booster 29x2.20, DTC compound, 30Tpi, wire, ETRTO 56-622
Brakes
Brakes
Shimano BR-MT200, resin pad
Cockpit
Stem
Velomann 3D forged Alloy 6061, +/-7°, 1.1/8mm, diam. 31.8mm, ext: 80mm-15/17", 90mm-19/21"
Handlebar
Velomann Flat top DB Alloy 6061-T6, width 720mm, diam. 31,8mm, 9° backsweep
Headset
Fsa TH888 forged steel cups ID diam.34mm, stack height 12,8+11=23,8mm, w/15mm cap
Seat
Saddle
Velomann, steel rails, PVC soft touch cover, 140mm width
Seatpost
Velomann AL2014 shaft w/alloy head, diam. 27.2mm, 0mm seatback, length 350mm
