Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Alivio, Altus -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Magma 29" alu, 1,1/8" HT, BSA 68mm, seatpost diam. 27,2mm, low clamp FD diam. 31,8mm bottom pull or Side-Swing, PM 160mm, dropouts 9x135mm QR, internal cable routing, sizes 15-17-19-21"
Suspension Fork
SR Suntour XCM HLO DS 29" 100mm
Drivetrain
Rear Derailleur
Shimano Alivio RDM3100 SGS 9sp
Front Derailleur
Shimano FD-M2020-TS low clamp diam. 31,8mm, dual pull, 64/69°, for 36T w/14T capacity, CL 48.8/51.8mm
Shift Levers
Shimano Alivio SL-M3100 2x9sp
Crank
Shimano FC-MT101-2, 36/22T, crank length: 170mm-15/17", 175mm-19/21"
Bottom Bracket
Shimano BB-UN101
Chain
Kmc HV900 9sp
Pedals
included
Wheels
Front Hub
Formula CL-1420
Rear Hub
Formula CL-1422
Rims
VelomannDP2.5, 622x25c
Tires
Kenda Booster 29x2.20
Brakes
Brakes
Shimano BR-MT200
Cockpit
Stem
Velomann ST92A +/-7°, 1.1/8", diam.31.8mm, ext: 80mm-15/17" and 90mm-19/21", 3D forged alloy 6061
Handlebar
Velomann rise MTB479A, width 720mm, diam.31,8mm, rise 15mm, backsweep 9°, PG Alloy 6061 sandblasted anodized
Headset
Fsa TH888
Seat
Saddle
Velomann, steel rails, PVC soft touch cover, 140mm width
Seatpost
Velomann AL2014 shaft w/alloy head, diam. 27.2mm, 0mm seatback, length 350mm
