Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork RockShox Judy Silver TK
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Magma 29 alu, 1.1/8" HT, BSA 68mm, seatpost diam. 27,2mm, HDM bottom pull or Side-Swing, PM 160mm, BOOST 9x141mm QR, internal cable routing, sizes 15-17-19-21"
Suspension Fork
Rock Shox Judy Silver TK 29" Solo Air 100mm
Drivetrain
Rear Derailleur
Shimano Deore RD-M6100 12sp
Shift Levers
Shimano Deore SL-M6100-R 1x12sp
Cassette
Shimano CS-M6100-12, 12sp, 10-51T
Crank
Shimano FC-MT511-1, 32T, crank length: 170mm-15", 175mm-17/21"
Bottom Bracket
included in the crankset
Chain
Shimano CN-M6100 12sp
Pedals
included
Wheels
Front Hub
Formula CL-1420
Rear Hub
Shimano FH-MT410-B
Rims
VelomannDP2.5, 622x25c
Tires
Kenda Booster 29x2.20
Brakes
Brakes
Shimano BR-MT200
Cockpit
Stem
Velomann 3D forged Alloy 6061, +/-7°, 1.1/8mm, diam. 31.8mm, ext: 80mm-15/17", 90mm-19/21"
Handlebar
Velomann Flat top DB Alloy 6061-T6, width 720mm, diam. 31,8mm, 9° backsweep
Headset
Fsa TH888
Seat
Saddle
Velomann, steel rails, PVC soft touch cover, 140mm width
Seatpost
Velomann AL2014 shaft w/alloy head, diam. 27.2mm, 0mm seatback, length 350mm
