Bianchi T-Tronik T-Type X7/X5 2025
2025 E-bike
Estimate price |
2,326$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Travel Front 63mm -
Fork Suntour NEX
-
Groupset X7, X5 -
Suspension Hardtail -
Motor Shimano 250W 60Nm mid-drive -
Battery 417Wh batteria integrata -
Drivetrain 1 × 9 -
Brakes Promax Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
T-Tronik T-Type taglia: 47,51 - Forcellini a sgancio rapido 9x135 mm - Montaggio post mount 160 tipo di freno a disco - Passaggio interno dei cavi nel DT
Suspension Fork
Suntour NEX-E25 DS 700C, escursione 63 mm, HT da 1-1/8", senza QR 9x100, rotore minimo 160 mm, massimo 180 mm, piantoni da 30 mm
Drivetrain
Rear Derailleur
SRAM X7, 9sp, max. 36T
Shift Levers
SRAM X5, 9sp
Crank
Shimano CHAINRING, SM-CRE61, 38T FSA SMN E-Bike Forged Crankset - SMN / 170mm
Bottom Bracket
included in the motor
Chain
KMC e9S NPBK
Pedals
VP black aluminum, axle 7mm, 113,5x110,5mm
Wheels
Front Hub
Shimano, HB-TX505,32H OLD:100MM AXLE:108MM, QR:133MM
Rear Hub
Shimano, FH-TX505-8, 32H 8/9/10/11-SPEED,OLD:135MM,ASSE:146MM,QR:170MM
Rims
EBIKE 650 TR 28" - ETRTO 622 x 23C, 32 fori, altezza 18mm
Tires
Chaoyang E-Liner City 700x45C, 60tpi
Brakes
Brakes
Promax, DSK-925
Cockpit
Stem
Velomann, forcella 28,6 mm ID Morsetto, 31,8 mm
Handlebar
Velomann 31,8/680 mm, ALTEZZA 20MM, SPESSORE 15
Headset
FSA HST STbk 1-1/8" 44H-N10P
Seat
Saddle
Selle Royal
Seatpost
Velomann, lunghezza 350 mm per la taglia SM e 400 mm per la MD, diam. 31,6 mm, fondello 0 mm
Motor & Battery
Motor
Shimano E6100, 250W, 60Nm
Battery
417Wh batteria integrata
