Bike details
Overview
Key information split into simple groups.
Frame summary
-
Category -
Frame Steel -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Bianchi Chromoly, lugged
Suspension Fork
Bianchi Chromoly, 1"
Cockpit
Headset
Included
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 46cm | 49cm | 51cm | 53cm | 55cm | 57cm | 59cm | 61cm |
|---|---|---|---|---|---|---|---|---|
| Bottom Bracket Height | 278 mm | 278 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm | 268 mm |
| Front Center | 579 mm | 585 mm | 584 mm | 586 mm | 592 mm | 602 mm | 607 mm | 612 mm |
| Top Tube Length | 502 mm | 512 mm | 517 mm | 527 mm | 542 mm | 552 mm | 567 mm | 577 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm | 590 mm | 610 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71 ° | 71.5 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 110 mm | 120 mm | 125 mm | 135 mm | 145 mm | 165 mm | 180 mm | 200 mm |
| Chainstay Length | 398 mm | 400 mm | 400 mm | 402 mm | 407 mm | 407 mm | 407 mm | 410 mm |
| Wheelbase | 970 mm | 978 mm | 974 mm | 978 mm | 989 mm | 1000 mm | 1005 mm | 1013 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Tipo Corsa Frameset belongs to the Bianchi Tipo model. There are 6 frames that carry this model name.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
General Road frames average price
Our math shows that the average cost of a dependable General Road frame is 2445$. However, even though the average price of a General Road frame is lower, you might still be able to get a top-quality frame. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
When Bianchi released this model in 2017, its price was 849$. Comparing this to the average General Road frame price, we see that the price is 187.99% smaller.
Tipo Corsa Frameset components
Fork material
Tipo Corsa Frameset has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the frame.
