Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Shimano GRX 400 Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
VIA NIRONE 7 ALL ROAD alloy, TC18, hydroforming tubing, internal cable, seatpost: 31.6mm, flat mount disc brake, thru axle 12x142mm, 40mm tire clearance, rack & fender eyelets, downtube underside bottle cage bosses, sizes 47-50-53-55-57-59-61-63cm
Suspension Fork
Carbon 1"1/8, flat mount, disc brake, thru axle 12x100mm
Drivetrain
Rear Derailleur
Shimano 105 RD-R7000 GS 11sp
Front Derailleur
Shimano 105 FD-R7000-L
Shift Levers
Shimano 105 ST-R7020 11sp
Crank
Shimano FC-RS510 50x34T, Crank Length: 170mm-44/53cm, 172.5mm-55/59cm, 175mm-60/63cm
Bottom Bracket
included in the crankset
Chain
Kmc X11-1 EPT finish, 11sp
Wheels
Front Hub
Formula - CL-712 road disc, alloy 32h, thru axle 12x100mm
Rear Hub
Formula - RXC-142S road disc, center lock, J-bend, thru axle 12xx142mm
Rims
Velomann GD24 disc 700c 622-21, profile 24mm
Tires
Vittoria Zaffiro V 32-622
Brakes
Brakes
Shimano BR-RX400
Brake Levers
included w/shifters
Cockpit
Stem
Velomann ST182A, Alloy 6061, raise +/ - 7°, height 38mm, Oversize, 1 1/8", Ext: 70mm-47cm, 90mm-50/53cm, 100mm-55cm,110mm-57/59cm, 120mm-61/63cm
Handlebar
Velomann RA35A Compact, Flat Top, alloy 6061 diam. 31,8mm, reach 80mm, drop 130mm, Size: 400mm-44/53cm, 420mm-55/59cm, 440mm-61cm
Headset
Fsa NO.8B/ZS4D
Seat
Saddle
Velomann 2302HRN, lenght/wide 280x145mm
