bixs Access-E10 2025
2025 E-bike
Estimate price |
6,160$
Weight | 27.5 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCR Air
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery BOSCH POWERTUBE, 625WH, RANGE EXTENDER CAPABLE -
Drivetrain 1 × 11 -
Brakes Shimano Deore Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ACCESS-E PREMIUM ALLOY HARDTAIL, 12X148MM BOOST
Suspension Fork
SUNTOUR SF25-XCR34X AIR DS, 100MM TRAVEL, 15X110MM
Drivetrain
Rear Derailleur
SHIMANO CUES RD-U6000, 11-SPEED
Shift Levers
SHIMANO CUES SL-U6000-11R
Cassette
SHIMANO CUES CS-LG400-11, 11-50T
Crank
FSA CK-320 / FSA STEEL MEGATOOTH, CL52, 38T
Chain
SHIMANO CUES CN-LG500
Wheels
Front Hub
SHIMANO HB-TC500-15-B, 32 HOLES
Rear Hub
SHIMANO FH-TC500-HM-B, 32 HOLES
Rims
ALEXRIMS EM30, 30MM INNER WIDTH
Tires
ONZA ALLEGRA, 29X2.25"
Brakes
Brakes
SHIMANO BL-M4100, BR-MT420 4-PISTON
Cockpit
Stem
SATORI VIPER, 0°, 31.8MM CLAMP
Handlebar
BIXS RIZER BAR, 15MM RISE, 760MM
Seat
Saddle
BIXS VL-3584
Seatpost
KIND SHOCK RAGE-I, Ø31.6MM, S: 100MM, M & L: 125MM, XL: 150MM
Motor & Battery
Motor
BOSCH PERFORMANCE CX SMART, 85NM
Battery
BOSCH POWERTUBE, 625WH, RANGE EXTENDER CAPABLE
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | A | B | C | D | E | F | G | H | I | J | K | LG | MD | Körpergrösse | Rahmengrösse |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
