bixs Campus 1 Pastel Green 2025
2025 Urban
Estimate price |
2,097$
Weight | 15.9 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NCX
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 10 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TOURING CONCEPT, ALLOY 6061, 700C
Suspension Fork
SUNTOUR SF17-NCX-D-COIL LO, TAPERED, HYDRAULIC LOCKOUT, 63MM
Drivetrain
Rear Derailleur
SHIMANO XT RD-T8000 SGS SHADOW DESIGN, TOP NORMAL, 10-SPEED
Shift Levers
SHIMANO DEORE SL-T6000, WITH OPTICAL GEAR DISPLAY
Cassette
SHIMANO CS-HG500-10, 11-34 TEETH, 10-SPEED
Crank
SHIMANO DEORE FC-T6010, 2-PIECE CRANKSET, 48-36-26 TEETH
Chain
SHIMANO CN-HG54 10-SPEED
Wheels
Front Hub
SHIMANO DH-3D37 HUB DYNAMO, 6V, 3W, 32 HOLES
Rear Hub
SHIMANO FH-QC400-HM, 32 HOLES
Rims
ALEXRIMS VOLAR 2.1, 32 HOLES, INNER WIDHT 21mm, 700C
Tires
SCHWALBE MARATHON PERFORMANCE, GREEN GUARD, 700x47C
Brakes
Brakes
SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:160mm, R:160mm ROTORS
Brake Levers
SHIMANO BL-MT201
Cockpit
Stem
BIXS AS-007N, 17°ANGLE, 31.8mm CLAMP
Handlebar
BIXS RIZER BAR, 700mm, 9°ANGLE, 15mm RISE, 31.8mm
Headset
FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER
Seat
Saddle
ERGON ST10 GEL
Seatpost
BIXS SP-3D2, M: 350mm, OTHERS: 400mm, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL | XXL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.679 mm | 1.672 mm | 1.661 mm | 1.639 mm |
| Bottom Bracket Height | 300 mm | 300 mm | 300 mm | 300 mm |
| Stack | 638 mm | 652 mm | 666 mm | 680 mm |
| Reach | 380 mm | 390 mm | 401 mm | 415 mm |
| Top Tube Length | 575 mm | 590 mm | 605 mm | 620 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 155 mm | 170 mm | 185 mm | 200 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1089 mm | 1105 mm | 1121 mm | 1137 mm |
| Wheels | 700 | 700 | 700 | 700 |
