bixs Campus-E20 Black 2025
2025 E-bike
Estimate price |
5,562$
Weight | 26.5 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 75mm -
Fork Suntour MOBIE
-
Groupset Nexus -
Suspension Hardtail -
Motor Shimano 250W 85Nm mid-drive -
Battery DARFON, 36V, 630Wh -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-TOURING CONCEPT, ALLOY 6061, 700C
Suspension Fork
SUNTOUR MOBIE 25 AIR 700C, LOR, 15x100mm AXLE, TAPERED, 75mm TRAVEL, REBOUND, LOCKOUT
Drivetrain
Shift Levers
SHIMANO NEXUS SL-C7000-5, REVO SHIFTER
Cassette
GATES SINGLE SPROCKET, 28 THEETH
Crank
SHIMANO STEPS FC-EM600, 39 TEETH
Bottom Bracket
STEPS, press-fit
Chain
GATES BELT DRIVE, 122 THEETH
Wheels
Front Hub
SHIMANO HB-TC500-15, 32 HOLES, 15x100mm THRU AXLE
Rear Hub
SHIMANO NEXUS, SG-C7000-5D, INTERNAL HUB GEAR, 32 HOLES, QR
Tires
SCHWALBE ENERGIZER PLUS, PERFORMANCE, GREEN-GUARD ADDIX 700x55C
Brakes
Brakes
SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Brake Levers
SHIMANO BL-MT201
Cockpit
Stem
BIXS AS-4002, ANGLE ADJUSTABLE, 31.8mm CLAMP
Handlebar
BIXS HB-RB12L RIZER BAR, 720mm, 15°ANGLE, 15mm RISE, 31.8mm
Headset
FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER
Seat
Saddle
ERGON ST10
Seatpost
BIXS SP-3D2, M: 350mm, OTHERS: 400mm, 31.6mm
Motor & Battery
Motor
SHIMANO STEPS EP8, 250 WATT
Battery
DARFON, 36V, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.774 mm | 1.754 mm | 1.735 mm |
| Bottom Bracket Height | 300 mm | 300 mm | 300 mm |
| Stack | 674 mm | 684 mm | 694 mm |
| Reach | 380 mm | 390 mm | 400 mm |
| Top Tube Length | 590 mm | 600 mm | 610 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 170 mm | 180 mm | 190 mm |
| Chainstay Length | 480 mm | 480 mm | 480 mm |
| Wheelbase | 1137 mm | 1148 mm | 1160 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
