bixs Campus-E20 Gor 2025
2025 E-bike
Estimate price |
5,683$
Weight | 27.3 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork Suntour
-
Groupset Gates CDX, Nexus -
Suspension Hardtail -
Motor Shimano 600W 85Nm mid-drive -
Battery DARFON 600WH, RANGE EXTENDER CAPABLE -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CAMPUS-E PREMIUM ALLOY HARDTAIL, 10X135MM BOLT ON
Suspension Fork
SUNTOUR SF21-MOBBIE34-D AIR DS, 80MM TRAVEL, 15X100MM
Drivetrain
Shift Levers
SHIMANO NEXUS SL-C7000-5
Cassette
GATES CDX SPROCKET, 28T
Crank
SHIMANO FC-EM600, GATES CDX, CL45.5, 39T
Chain
GATES CDX BELT, 122T
Wheels
Front Hub
SHIMANO HB-TC500-15, 32 holes
Rear Hub
SHIMANO NEXUS SG-C7000-5D, INTERNAL HUB GEAR
Rims
ALEXRIMS DM21, 21MM INNER WIDTH
Tires
SCHWALBE ENERGIZER PLUS, 700X55C, PERFORMANCE, GREEN-GUARD ADDIX
Brakes
Brakes
SHIMANO BL-MT201, BR-MT200 2-PISTON
Cockpit
Stem
SATORI PYTHON, ANGLE ADJUSTABLE, 31.8MM CLAMP
Handlebar
BIXS RIZER BAR, 15MM RISE, 700MM
Seat
Saddle
BIXS VL-4479
Seatpost
BIXS SEATPOST, Ø31.6MM, 350MM
Motor & Battery
Motor
SHIMANO EP801, 85NM
Battery
DARFON 600WH, RANGE EXTENDER CAPABLE
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | A | B | C | D | E | F | G | H | I | J | K | LG | MD |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
