Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 75mm -
Fork Suntour MOBIE
-
Groupset Shimano -
Suspension Hardtail -
Motor Shimano 250W 85Nm mid-drive -
Battery DARFON, 36V, 630Wh -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eTOURING CONCEPT, ALLOY 6061, DEEP INSTEP 700C
Suspension Fork
SUNTOUR MOBIE 25 AIR, 700C, TAPERED, 75mm TRAVEL, LOCKOUT
Drivetrain
Shift Levers
SHIMANO SW-E6010
Cassette
GATES SINGLE SPROCKET, 28 THEETH
Crank
SHIMANO STEPS FC-EM600, 39 TEETH
Bottom Bracket
STEPS, press-fit
Chain
GATES BELT DRIVE, 122 THEETH
Pedals
VP 831, INLEAD GRIP TREAD
Wheels
Front Hub
SHIMANO HB-MT410, 32 HOLES, 15x100mm THRU AXLE
Rear Hub
SHIMANO NEXUS Di2, SG-C7050-5D, INTERNAL HUB GEAR, 32 HOLES, QR
Rims
ALEXRIMS DM-21, 32 HOLES, INNER WIDTH 21mm, 700C
Tires
SCHWALBE MARATHON ALMOTION EVO, V-GUARDA ADDIX, 700X55C
Brakes
Brakes
SHIMANO BR-MT420, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:180mm, R:180mm ROTORS
Brake Levers
SHIMANO BL-MT402-3A
Cockpit
Stem
ERGOTEC BARRACUDA, BARBORE: 31.8MM, 1 1/8", ANGLE: 20°
Handlebar
BIXS HB-RB12L RIZER BAR, 720MM, 15°ANGLE, 25MM RISE, 31.8MM
Seat
Saddle
ERGON ST CORE EVO TWIN SHELL DESIGN
Seatpost
BIXS SP-3D2, 350mm, 31.6mm
Motor & Battery
Motor
SHIMANO STEPS EP8, 250 WATT
Battery
DARFON, 36V, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
CAMPUS-EX DI belongs to the Bixs E Campus Ex model. There is 1 e-bike that carries this model name.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Commuter e-bikes
Our math shows that the average cost of a dependable Commuter e-bike is 2569$. However, this doesn’t mean that if you spend less money on a Commuter e-bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2023 and its price was 5998$. Comparing this to the average Commuter e-bike price, we see that the price is 133.48% higher.
CAMPUS-EX DI components
Fork
The Suntour MOBIE is included from the factory. It has a travel distance of 75mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The CAMPUS-EX DI 2023 e-bike is equipped with 700c aluminum wheels when leaving the factory. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. BiXS CAMPUS-EX DI is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
