bixs Core 400 Soft Purple / Dark Silver – Grass Green 2025
2025 Mountain
Estimate price |
1,480$
Weight | 13.9 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork RockShox Judy Silver TK
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SPORT GEOMETRY ALLOY 6061 HYDROF. T.B. 148x12mm BOOST DROPOUT, Hardtail 29"
Suspension Fork
ROCK SHOX JUDY SILVER TK 29", SOLO AIR SPRING, TAPERED, 15x110mm AXLE, 100mm TRAVEL, REBOUND, LOCKOUT
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift Levers
SHIMANO DEORE SL-M6100, WITH OPTICAL GEAR DISPLAY
Cassette
SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED
Crank
SHIMANO FC-MT511, 2-PIECE CRANKSET, 32 TEETH
Chain
SHIMANO CN-M6100 12-SPEED
Wheels
Front Hub
SHIMANO HB-TC500-15-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Rear Hub
SHIMANO FH-TC500-MS-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Rims
ALEXRIMS MD-30, 32 HOLES, INNER WIDTH 30mm, 29"
Tires
SCHWALBE SMART SAM K-GUARD, 29x2.35"
Brakes
Brakes
SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Brake Levers
SHIMANO BL-MT201
Cockpit
Stem
BIXS AS-M03, 0°ANGLE, 31.8mm CLAMP
Handlebar
BIXS HB-RB12L, 740mm, 9°ANGLE, 25mm RISE, 31.8mm
Headset
FSA NO.57B, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 8.2mm TOP COVER
Seat
Saddle
BIXS VL-3533
Seatpost
BIXS SP-3D2, S & M: 350mm, OTHERS: 400mm, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | A | B | C | D | E | F | G | H | I | J | K | LG | MD | Körpergrösse | Rahmengrösse |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
