Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Suntour XCR Air
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 85Nm mid-drive -
Battery DARFON, 36V, 500Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eSPORT GEOMETRY, ALLOY 6061 HYDROFORMED D.B. TUBES, HARDTAIL, DROPOUT 148x12mm BOOST, 29"
Suspension Fork
SUNTOUR XCR34 AIR LO-R 29", BOOST, TAPERED, AIR SPRING, 120mm TRAVEL, REBOUND, LOCKOUT
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M5100 SGS SHADOW PLUS DESIGN, 11-SPEED
Shift Levers
SHIMANO DEORE SL-M5100, WITH OPTICAL GEAR DISPLAY
Cassette
SHIMANO CS-M5100, 11-51 THEETH, 11-SPEED
Crank
SHIMANO STEPS FC-EM600, 34 TEETH
Bottom Bracket
STEPS, press-fit
Chain
SHIMANO CN-HG701-11
Pedals
PU-857
Wheels
Front Hub
SHIMANO HB-MT400-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Rear Hub
SHIMANO FH-MT400-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Rims
ALEXRIMS EM-35, 32 HOLES, INNER WIDTH 35mm, 29"
Tires
SCHWALBE SMART SAM PERFORMANCE, ADDIX, 29x2.6"
Brakes
Brakes
SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Brake Levers
SHIMANO BL-MT201
Cockpit
Stem
BIXS 0°ANGLE, 35mm CLAMP
Handlebar
BIXS RIZER BAR, 760mm, 9° BACKSWEEP, 15mm RISE, 35mm
Seat
Saddle
BIXS VL-3533
Seatpost
BIXS, 15" & 17": 350mm, OTHERS: 400mm, 31.6mm
Motor & Battery
Motor
SHIMANO STEPS EP8, 250 WATT
Battery
DARFON, 36V, 500Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
CORE-E22 is part of the Bixs E Core E22 model. BiXS released 1 e-bike variation of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail e-bikes average price
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 4440$. Comparing this to the average Trail e-bike price, we see that the price is 31.95% higher.
Overview of components
Fork
This e-bike has the Suntour XCR Air fork installed. The fork’s travel is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When it comes to wheels, the CORE-E22 e-bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. BiXS CORE-E22 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
CORE-E22 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
