Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset Deore, Shimano -
Suspension Hardtail -
Motor Shimano 250W 85Nm mid-drive -
Battery DARFON, 36V, 500Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-SPORT GEOMETRY, ALLOY 6061 HYDROFORMED D.B. TUBES, HARDTAIL, DROPOUT 148X12MM BOOST, 29"
Suspension Fork
SUNTOUR XCM34 DS 29", COIL SPRING, BOOST, TAPERED, 15MM AXLE, 120MM TRAVEL
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M5120 SGS SHADOW PLUS DESIGN, 10-SPEED
Front Derailleur
SHIMANO CHAIN DEVICE SM-CDE70
Shift Levers
SHIMANO DEORE SL-M6000, WITH OPTICAL GEAR DISPLAY
Cassette
SHIMANO CS-M4100, 11-46 THEETH, 10-SPEED
Crank
SHIMANO STEPS FC-E8000, 34 TEETH
Bottom Bracket
STEPS, press-fit
Chain
SHIMANO CN-E6090-10 FOR E-BIKE
Pedals
PU-857
Wheels
Front Hub
SHIMANO HB-MT400-B, 32 HOLES, 15x110mm BOOST THRU AXLE
Rear Hub
SHIMANO FH-MT400-B, 32 HOLES, 12x148mm BOOST THRU AXLE
Rims
ALEXRIMS MD-35, 32 HOLES, INNER WIDTH 35MM, 29"
Tires
SCHWALBE SMART SAM K-GUARD, 29x2.6"
Brakes
Brakes
SHIMANO BR-MT200, HYDRAULIC DISC BRAKE WITH RESIN PADS, F:180mm, R:180mm ROTORS
Brake Levers
SHIMANO BL-MT201
Cockpit
Stem
BIXS 0°ANGLE, 35mm CLAMP
Handlebar
BIXS RIZER BAR, 760mm, 9° BACKSWEEP, 15mm RISE, 35mm
Seat
Saddle
BIXS VL-3493 E-BIKE
Seatpost
BIXS VL-3533
Motor & Battery
Motor
SHIMANO STEPS EP8, 250 WATT
Battery
DARFON, 36V, 500Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
CORE-E32 completes the Bixs E Core E32 model. There is 1 e-bike that carries this model name.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail e-bikes
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
When BiXS released this model in 2023, its price was 3884$. In conclusion, this e-bike price is 15.42% higher than the price of the average Trail e-bike.
Overview of components
Fork
BiXS CORE-E32 2023 e-bike is equipped with the Suntour XCM fork, and has 120mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels size
As for the wheels, BiXS CORE-E32 2023, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. BiXS CORE-E32 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
BiXS CORE-E32 e-bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
