bixs District-E20 2025
2025 E-bike
Estimate price |
3,691$
Weight | 15.8 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset CUES -
Suspension Rigid -
Motor MAHLE 40Nm hub-drive -
Battery MAHLE FULL INTEGRATED, 250Wh, RANGE EXTENDER CAPABLE -
Drivetrain 1 × 11 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DISTRICT-E PREMIUM ALLOY HARDTAIL, 10x135mm BOLT ON, FLAT MOUNT DISC
Suspension Fork
PREMIUM ALLOY RIGID FORK, 12x100mm
Drivetrain
Rear Derailleur
SHIMANO CUES RD-U6000, 11-SPEED
Shift Levers
SHIMANO CUES SL-U6000-11R
Cassette
SHIMANO CUES CS-LG400-11, 11-50T
Crank
SHIMANO CUES FC-U6000-1, CL50, 40T
Chain
SHIMANO CUES CN-LG500
Chain Guide
SHIMANO FC CHAINGUARD
Wheels
Front Hub
JOYTECH D791SB-12, 32 HOLES
Rear Hub
MAHLE X35, 32 HOLES, SHIMANO HYPERGLIDE FREEHUB
Rims
ALEXRIMS DM21, 21mm INNER WIDTH
Tires
SCHWALBE G-ONE RS EVO, SUPER RACE, V-GUARD, 700x45C
Brakes
Brakes
SHIMANO BL-RS600, BR-RS405
Cockpit
Stem
SATORI VIPER, 0°, 31.8mm CLAMP
Handlebar
BIXS RIZER BAR, 25mm RISE, 680mm
Seat
Saddle
BIXS VL-3569
Seatpost
BIXS SEATPOST, ø31.6mm, S & M: 350mm, L & XL: 400mm
Motor & Battery
Motor
MAHLE X35, 40Nm
Battery
MAHLE FULL INTEGRATED, 250Wh, RANGE EXTENDER CAPABLE
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | A | B | C | D | E | F | G | H | I | J | K | LG | MD | Körpergrösse | Rahmengrösse |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
