bixs Lane-E16 2025
2025 E-bike
Estimate price |
8,629$
Weight | 26.4 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Performance Float 38
-
Groupset XT -
Suspension Full -
Motor Yamaha 250W mid-drive -
Battery SIMPLO, 36V, 630Wh -
Drivetrain 1 × 12 -
Brakes Shimano XT Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-ENDURO GEOMETRY, ALLOY 6061, 160mm TRAVEL, ALLOY ROCKER, DROPOUT 148x12mm BOOST, 29"
Suspension Fork
FOX 38 FLOAT PERFORMANCE, 15x110mm AXLE, TAPERED, GRIP, TRAVEL: 170mm, 3-POS. LEVER
Rear Shock
FOX FLOAT X2 PERFORMANCE, 2 POSITION LEVER, 205x65, TRUNNION MOUNT, HARDWARE: 20mmx8mm
Drivetrain
Rear Derailleur
SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift Levers
SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV
Cassette
SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED
Crank
FSA CK762 WIDER, ISIS, BOOST, STEEL CHAINRING, 34 TEETH
Chain
KMC E12 SPORT, EPT ANTI-RUST
Wheels
Front Hub
DT SWISS WHEELSET SPLINE HX-1700, 15x110mm THRU AXLE
Rear Hub
DT SWISS WHEELSET SPLINE HX-1700, 12x148mm BOOST, THRU AXLE
Tires
ONZA AQUILA, KEVLAR FOLDABLE, TUBELESS READY, 29x2.5",GRC
Brakes
Brakes
SHIMANO XT BR-M8120, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203mm, R:203mm ROTORS
Brake Levers
SHIMANO XT BL-M8100, ISPEC EV
Cockpit
Stem
RACE FACE TURBINE R, 0°ANGLE, 35MM CLAMP
Handlebar
RACE FACE TURBINE R, 780mm/800mm, 35mm RISE, 8° BACKSWEEP, 35mm
Headset
ACROS CUSTOMIZED FOR INTEGRATED CABLE ROUTING, 1.5" BLOCK LOCK
Seat
Saddle
ERGON SM10 E-MOUNTAIN
Seatpost
KIND SHOCK LEV SI, S: 100mm, M: 125mm, L: 150mm, XL: 175mm TRAVEL, SHIMANO REMOTE LEVER, 31.6mm
Motor & Battery
Motor
YAMAHA PW-X 3 SERIES, 250 WATT
Battery
SIMPLO, 36V, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | A | B | C | D | E | F | G | H | I | J | K | LG | MD | Körpergrösse | Rahmengrösse |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
