bixs Lane-EX 2025
2025 E-bike
Estimate price |
9,864$
Weight | 25.9 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Factory Float 38
-
Groupset X01 Eagle AXS, EX1 -
Suspension Full -
Motor Yamaha 250W mid-drive -
Battery SIMPLO, 36V, 630Wh -
Drivetrain 1 × 12 Electronic -
Brakes Magura MT7 Pro Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-ENDURO GEOMETRY, ALLOY 6061, 160mm TRAVEL, ALLOY ROCKER, DROPOUT 148x12mm BOOST, 29"
Suspension Fork
FOX 38 FLOAT FACTORY, KASHIMA, 15x110mm AXLE, TAPERED, GRIP2, TRAVEL: 170mm, 4-WAY ADJUSTABILITY
Rear Shock
FOX FLOAT X2 FACTORY KASHIMA, 2 POSITION LEVER, 205x65, TRUNNION MOUNT, HARDWARE: 20mmx8mm
Drivetrain
Rear Derailleur
SRAM X01 EAGLE AXS, 12-SPEED
Shift Levers
SRAM EC AXS CONTROLLER RIGHT HAND ROCKER, 2 BUTTON, 12-SPEED
Cassette
SRAM XG-1275 EAGLE, 10-52 TEETH, 12-SPEED
Crank
SRAM EX1 EAGLE X-Sync, 34 TEETH
Chain
SRAM CN-SX EAGLE
Wheels
Front Hub
DT SWISS WHEELSET SPLINE HX-1501, 15x110mm THRU AXLE
Rear Hub
DT SWISS WHEELSET SPLINE HX-1501, 12x148mm BOOST, THRU AXLE
Tires
ONZA AQUILA, KEVLAR FOLDABLE, TUBELESS READY, 29x2.5",GRC
Brakes
Brakes
MAGURA MT7, 4-PISTON HYDRAULIC DISC BRAKE, F:220mm, R:203mm ROTORS
Brake Levers
MAGURA MT7, 1-FINGER HC ALUMINUM LEVER BLADE
Cockpit
Stem
FASERWERK FULL CARBON COCKPIT
Handlebar
FASERWERK FULL CARBON COCKPIT, 800MM, 9° ANGLE, 15MM RISE
Headset
ACROS CUSTOMIZED FOR INTEGRATED CABLE ROUTING, 1.5" BLOCK LOCK
Seat
Saddle
ERGON SM10 E-MOUNTAIN
Seatpost
ROCK SHOX REVERB AXS, S: 100MM, M: 125mm, L: 150mm, XL: 170mm TRAVEL, WIRELESS REMOTE, 31.6mm
Motor & Battery
Motor
YAMAHA PW-X 3 SERIES, 250 WATT
Battery
SIMPLO, 36V, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | A | B | C | D | E | F | G | H | I | J | K | LG | MD | Körpergrösse | Rahmengrösse |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
