bixs Peak-E14 Purple – Anthrazit 2025
2025 E-bike
Estimate price |
6,778$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox 35 Silver
-
Groupset Deore -
Suspension Full -
Motor Yamaha 250W mid-drive -
Battery SIMPLO, 36V, 630WH -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-TRAIL GEOMETRY, ALLOY 6061, 140MM TRAVEL, ALLOY ROCKER, DROPOUT 148X12MM BOOST, 29"
Suspension Fork
ROCK SHOX 35 SILVER TK SOLO AIR 29", 15X110MM AXLE, TAPERED, 150MM TRAVEL, REBOUND, COMP. TO LOCK
Rear Shock
ROCK SHOX DELUX SELECT+ RT, LEVER, 185X55MM, TRUNNION MOUNT, HARDWARE: 20MMX8MM
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift Levers
SHIMANO DEORE SL-M6100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV
Cassette
SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED
Crank
FSA CK320, ISIS, BOOST, STEEL CHAINRING, 34 TEETH
Chain
KMC E12 SPORT, EPT ANTI-RUST
Wheels
Front Hub
SUNRINGLE WHEELSET DUROC 37SD COMP, 32 HOLES, 15X110MM THRU AXLE
Rear Hub
SUNRINGLE WHEELSET DUROC 37SD COMP, 32 HOLES, 12X148MM BOOST, THRU AXLE
Tires
ONZA IBEX, KEVLAR FOLDABLE, TUBELESS READY, 29X2.6"
Brakes
Brakes
SHIMANO BR-MT420, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203MM, R:203MM ROTORS
Brake Levers
SHIMANO BL-M4100, ISPEC EV
Cockpit
Stem
BIXS 0°ANGLE, 35MM CLAMP
Handlebar
BIXS RIZER BAR, 780MM, 9° BACKSWEEP, 15MM RISE, 35MM
Headset
ACROS CUSTOMIZED FOR INTEGRATED CABLE ROUTING, 1.5" BLOCK LOCK
Seat
Saddle
BIXS VL-3575
Seatpost
KIND SHOCK RAGEI, S: 100MM, M: 125MM, L: 150MM, XL: 170MM TRAVEL, WESTY LEVER REMOTE, 31.6MM
Motor & Battery
Motor
YAMAHA PW-X 3 SERIES, 250 WATT
Battery
SIMPLO, 36V, 630WH
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | A | B | C | D | E | F | G | H | I | J | K | LG |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
