bixs Sauvage-E25 2025
2025 E-bike
Estimate price |
7,642$
Weight | 25.1 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 160mm -
Travel Rear 150mm -
Fork RockShox Yari RC
-
Groupset Deore -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery SIMPLO, 36V, 630Wh -
Drivetrain 1 × 12 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
E-TRAIL GEOMETRY, ALLOY 6061, 150mm TRAVEL, ALLOY ROCKER, DROPOUT 148x12mm BOOST, 29"
Suspension Fork
ROCK SHOX YARI RC 29"/27.5"+, BOOST 15x110mm, TAPERED, 160mm TRAVEL, REBOUND, COMPRESSION TO LOCK
Rear Shock
FOX FLOAT DPS PERFORMANCE, LV, EVOL, 3 POS, 205x65, TRUNNION MOUNT, HARDWARE: 21.8mmx8mm
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift Levers
SHIMANO DEORE SL-M6100, CLAMP TYPE
Cassette
SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED
Crank
SHIMANO FC-EM600, 34 TEETH
Chain
SHIMANO CN-M6100 12-SPEED
Wheels
Front Hub
SUNRINGLE WHEELSET DUROC 35 COMP, 28 HOLES, 15x110mm THRU AXLE
Rear Hub
SUNRINGLE WHEELSET DUROC 35 COMP, 28 HOLES, 12x148mm BOOST, THRU AXLE
Rims
SUNRINGLE WHEELSET DUROC 35 COMP, TLR, 28 HOLES, INNER WIDTH 32mm, 29"
Tires
SCHWALBE MAGIC MARY EVO SUPER TRAIL, ADDIX SOFT, TL EASY, 29x2.4"
Brakes
Brakes
SHIMANO BR-MT520, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203mm, R:203mm ROTORS
Brake Levers
SHIMANO BL-MT501
Cockpit
Stem
BIXS 0°ANGLE, 35mm CLAMP
Handlebar
BIXS RIZER BAR, 780mm, 9° BACKSWEEP, 15mm RISE, 35mm
Headset
FSA NO.57E, 1-1/8" UPPER AND 1.5" LOWER BEARING WITH 12.3mm TOP COVER
Seat
Saddle
BIXS E-MTB
Seatpost
KIND SHOCK RAGEi, M & L: 125mm, XL: 150mm TRAVEL, SOUTHPAW-ALLOY REMOTE LEVER, 31.6mm
Motor & Battery
Motor
SHIMANO STEPS EP8, 250 WATT
Battery
SIMPLO, 36V, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.351 mm | 1.336 mm | 1.321 mm |
| Bottom Bracket Height | 360 mm | 360 mm | 360 mm |
| Front Center | 764 mm | 775 mm | 786 mm |
| Rake | 51 mm | 52 mm | 52 mm |
| Trail | 107 mm | 106 mm | 106 mm |
| Stack | 608 mm | 612 mm | 617 mm |
| Reach | 450 mm | 458 mm | 467 mm |
| Top Tube Length | 627 mm | 637 mm | 647 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 430 mm | 460 mm | 500 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1214 mm | 1225 mm | 1236 mm |
| Bottom Bracket Drop | 14 mm | 14 mm | 14 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
