bixs Sign 220 2025
2025 Mountain
Estimate price |
5,790$
Weight | 13.5 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 130mm -
Travel Rear 120mm -
Fork Fox Rhythm Float 34
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Shimano Deore Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TRAIL GEOMETRY, FULL CARBON FRAME, 120mm TRAVEL, DROPOUT 148x12mm BOOST, 29"
Suspension Fork
FOX 34 FLOAT RHYTHM 29", 15x110mm AXLE, TAPERED, GRIP, TRAVEL: 130mm, SWEEP ADJUST LEVER
Rear Shock
FOX FLOAT DPS PERFORMANCE ELITE, LV, EVOL, 2 POS REMOTE, 165x45, TRUNNION MOUNT, HARDWARE: 25mmx8mm
Drivetrain
Rear Derailleur
SHIMANO DEORE RD-M6100 SGS SHADOW PLUS DESIGN, 12-SPEED
Shift Levers
SHIMANO DEORE SL-M6100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV
Cassette
SHIMANO CS-M6100, 10-51 THEETH, 12-SPEED
Crank
SHIMANO DEORE FC-M6100, 32 TEETH
Chain
SHIMANO CN-M6100 12-SPEED
Wheels
Front Hub
DT SWISS WHEELSET SPLINE M-1900, 28 HOLES, 15x110mm THRU AXLE
Rear Hub
DT SWISS WHEELSET SPLINE M-1900, 28 HOLES, 12x148mm BOOST, THRU AXLE
Rims
DT SWISS WHEELSET SPLINE M-1900 TLR, 28 HOLES, INNER WIDTH 30mm, 29"
Tires
ONZA PORCUPINE, KEVLAR FOLDABLE, TUBELESS READY, 29x2.40"
Brakes
Brakes
SHIMANO DEORE BR-M6120/BR-M6100, HYDRAULIC DISC BRAKE WITH RESIN PADS, 180mm ROTORS
Brake Levers
SHIMANO BL-M6100, ISPEC EV
Cockpit
Stem
RACE FACE AEFFECT R, 0°ANGLE, 35mm CLAMP
Handlebar
RACE FACE AEFFECT, 760mm, 20mm RISE, 8° BACKSWEEP, 35mm
Headset
STSF17 INTEGRATED WITH CABLE INTEGRAGTION AND CABLE ENTRY DUSTCAP 1.5" UPPER AND LOWER BEARING
Seat
Saddle
BIXS VL-1A47
Seatpost
KIND SHOCK LEV SI, S: 100mm, M & L: 125mm, XL: 150mm TRAVEL, SHIMANO REMOTE LEVER, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.516 mm | 1.448 mm | 1.405 mm | 1.357 mm |
| Stack | 599 mm | 608 mm | 618 mm | 631 mm |
| Reach | 395 mm | 420 mm | 440 mm | 465 mm |
| Top Tube Length | 558 mm | 587 mm | 610 mm | 640 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 500 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 125 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1122 mm | 1151 mm | 1175 mm | 1206 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
