bixs Sign-E13 Carbon 2025
2025 E-bike
Estimate price |
10,234$
Weight | 18.9 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Performance Elite Float 36
-
Groupset XT -
Suspension Full -
Motor Shimano 600W 85Nm mid-drive -
Battery DARFON FULL INTEGRATED, 400Wh, RANGE EXTENDER CAPABLE FOR SIZE XL, L, M -
Drivetrain 1 × 12 -
Brakes Shimano XT Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SIGN-E CARBON FULLSUSPENSION, 130mm TRAVEL, 12x148mm BOOST, POST MOUNT DISC
Suspension Fork
FOX 36 FLOAT PERFORMANCE ELITE FIT4, 140mm TRAVEL, 15x110mm, 44mm OFFSET
Rear Shock
FOX FLOAT DPS PERFORMANCE ELITE, 3 POSITION LEVER, STANDARD MOUNT, 210x55mm, HARDWARE: 30/20x8mm
Drivetrain
Rear Derailleur
SHIMANO XT RD-M8100-SGS, 12-SPEED
Shift Levers
SHIMANO XT SL-M8100-IR
Cassette
SHIMANO SLX CS-M7100-12, 10-51T
Crank
SHIMANO FC-M8150, SM-CRE80-12, CL55, 34T
Chain
SHIMANO XT CN-M8100
Chain Guide
SHIMANO CD-EM800, 34-38T
Wheels
Tires
ONZA PORCUPINE, 29x2.4", TRC, TUBELESS READY
Brakes
Brakes
SHIMANO XT BL-M8100, BR-M8120 4-PISTON
Cockpit
Stem
SATORI URSA, 0°, 35mm CLAMP
Handlebar
BIXS RIZER BAR, 25mm RISE, 780mm
Seat
Saddle
BIXS-VL-4432
Seatpost
KIND SHOCK LEV INTEGRA, ø31.6mm, S: 100mm, M: 125mm, L: 150mm, XL: 175mm
Motor & Battery
Motor
SHIMANO EP801, 85NM
Battery
DARFON FULL INTEGRATED, 400Wh, RANGE EXTENDER CAPABLE FOR SIZE XL, L, M
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | A | B | C | D | E | F | G | H | I | J | K | LG |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
