Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Fox Factory Float 34
-
Groupset XT, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery DARFON, 36V, 630Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
eTRAIL GEOMETRY, ALLOY 6061, D.R.T. 130mm TRAVEL, ALLOY ROCKER, DROPOUT 148x12mm BOOST, 29"
Suspension Fork
FOX 34 FLOAT FACTORY 29", KASHIMA, 15x110mm AXLE, TAPERED, FIT4, TRAVEL: 130mm, 3-POSITION LEVER
Drivetrain
Rear Derailleur
SHIMANO XT RD-M8100 SGS SHADOW PLUS DESIGN, 12-SPEED
Front Derailleur
SHIMANO CHAIN DEVICE SM-CDE80
Shift Levers
SHIMANO XT SL-M8100, DIRECT ATTACH TO BRAKE LEVER, ISPEC EV
Cassette
SHIMANO CS-M8100, 10-51 THEETH, 12-SPEED
Crank
SHIMANO STEPS FC-EM600, 34 TEETH
Bottom Bracket
STEPS, press-fit
Chain
SHIMANO CN-M8100 12-SPEED
Wheels
Front Hub
DT SWISS WHEELSET SPLINE HX-1501, 15x110mm THRU AXLE
Rear Hub
DT SWISS WHEELSET SPLINE HX-1501, 12x148mm BOOST, THRU AXLE
Rims
DT SWISS WHEELSET SPLINE HX 1501 TLR, INNER WIDTH 30mm, 29"
Tires
SCHWALBE WICKED WILL EVO SUPER TRAIL, ADDIX SPEEDGRIP, TL EASY, 29X2.4"
Brakes
Brakes
SHIMANO XT BR-M8120, 4-PISTON HYDRAULIC DISC BRAKE, RESIN PADS, F:203mm, R:203mm ROTORS, ICE TECH
Brake Levers
SHIMANO XT BL-M8100, ISPEC EV
Cockpit
Stem
RACE FACE TURBINE R, 0°ANGLE, 35mm CLAMP
Handlebar
RACE FACE TURBINE R, 780mm, 20mm RISE, 8° BACKSWEEP, 35mm
Seat
Saddle
ERGON SM10 E-MOUNTAIN SPORT MEN
Seatpost
FOX TRANSFER FACTORY KASHIMA, S: 100MM, M & L: 125MM, XL: 150MM TRAVEL, REMOTE, 30.9MM
Motor & Battery
Motor
SHIMANO STEPS EP8, 250 WATT
Battery
DARFON, 36V, 630Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
SIGN-EX is a Bixs E Sign Ex model. BiXS launched 1 e-bike of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail e-bikes average price
Our math shows that the average cost of a dependable Trail e-bike is 3365$. However, you could also get a good Trail e-bike even if you pay a lower amount than the average price. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
This e-bike was released in 2023 and its price was 8891$. If we compare this with the average Trail e-bike cost we notice that the price is 164.22% more expensive.
Overview of components
Fork
The Fox Factory Float 34 is included from the factory. It has a travel distance of 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
The wheels on SIGN-EX are the 29″ aluminum type. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
BiXS SIGN-EX comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
