Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset CUES -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
MD
167cm - 180cm
LG
178cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpenchallenge Premium Aluminium | Smoothwelded | Powder Coat Finish | Internal Cable Routing | Flat Mount Disc | 12 x 142mm Thru-Axle
Suspension Fork
Alpenchallenge Premium Aluminium | Fender Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
Drivetrain
Rear Derailleur
SHIMANO CUES (RD-U6000)
Shift Levers
SHIMANO CUES (SL-U6000)
Cassette
SHIMANO CUES (CS-LG400)
Crank
FSA Vero Pro
Bottom Bracket
BSA Threaded Bottom Bracket
Chain
SHIMANO CN-LG500 Linkglide
Wheels
Rims
PFR300
Tires
Vittoria Randonneur | 37mm
Brakes
Brakes
SHIMANO BL-MT200 Levers | BR-UR300 Calipers
Cockpit
Stem
BMC RSM 01
Handlebar
BMC LSB 03
Seat
Saddle
Selle Royal Vivo
Seatpost
BMC LSP 02
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.422 mm | 1.459 mm | 1.477 mm |
| Front Center | 631 mm | 657 mm | 677 mm | 703 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 79 mm | 79 mm | 79 mm | 79 mm |
| Stack | 560 mm | 590 mm | 620 mm | 650 |
| Reach | 400 mm | 415 mm | 425 mm | 440 mm |
| Top Tube Length | 560 mm | 584 mm | 603 mm | 626 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 555 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 133 mm | 165 mm | 197 mm | 229 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1062 mm | 1088 mm | 1109 mm | 1135 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 760 mm | 790 mm | 819 mm | 838 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Max Height | 169 cm | 180 cm | 191 cm | cm |
