Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset RED AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes SRAM Hydraulic Disc
Sizing
Recommended size guide.
MD
172cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Speedmachine 01 Premium Carbon | ICS Technology Stealth Cable Routing | Integrated Fuel Tank 1200 Hydration System | Integrated Rear Storage 260 | Stealth Dropout Design | Flat Mount Disc | 142x12mm Thru-Axle
Suspension Fork
Speedmachine 01 Premium Carbon | ICS Technology | Stealth Cable Routing | Stealth Dropout Design | Flat Mount Disc | 100 x 12mm Thru-Axle
Drivetrain
Rear Derailleur
SRAM RED AXS (RD-RED-E-E1)
Front Derailleur
SRAM RED AXS (FD-RED-E-E1)
Shift Levers
SRAM Blip AXS Wireless 4 units
Cassette
SRAM RED (CS-XG-1290-E1)
Crank
SRAM RED AXS (FC-RED-P-E1)
Bottom Bracket
SRAM T47x68 DUB
Chain
SRAM RED (CN-RED-E1)
Wheels
Rims
DT Swiss ARC 1100 DICUT | 65mm
Tires
Pirelli P Zero Race TLR RS | Tubeless | 26 / 28mm
Brakes
Brakes
SRAM S-900 Aero HRD Disc Brake
Cockpit
Handlebar
BMC Speedmachine Flat Cockpit | Profile Design Aeria Ultimate with Ergo+ Armrests and 45/25 SLC Aerobar Extensions
Seat
Saddle
Fizik Transiro Aeris Long Distance R3
Seatpost
BMC Speedmachine Seatpost 0 Offset | 0mm, 12.5mm, 25mm Offsets
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.603 mm | 1.598 mm | 1.59 mm |
| Bottom Bracket Height | 274 mm | 264 mm | 264 mm |
| Front Center | 578 mm | 606 mm | 646 mm |
| Stack | 558 mm | 588 mm | 628 mm |
| Reach | 348 mm | 368 mm | 395 mm |
| Seat Tube Angle | 80 ° | 80 ° | 82.4 ° |
| Seat Tube Length | 460 mm | 525 mm | 551 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm |
| Wheelbase | 974 mm | 1000 mm | 1040 mm |
| Bottom Bracket Drop | 62 mm | 72 mm | 72 mm |
| Standover Height | 766 mm | 806 mm | 837 mm |
| Wheels | 700 | 700 | 700 |
| Rider Max Height | 174 cm | 185 cm | cm |
