Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Miche -
Suspension Rigid
Sizing
Recommended size guide.
MD
170cm - 185cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Trackmachine AL Premium Aluminium with Vmax Aero Design
Suspension Fork
Trackmachine Carbon subA Aero Technology
Drivetrain
Cassette
Miche Pista Steel
Crank
Miche Advanced Pista
Bottom Bracket
MICHE Primato JIS 107 - 110mm
Chain
Miche Pista 1/8"
Wheels
Rims
DT Swiss T 1800 Classic | 32mm
Tires
Pirelli P ZERO Road | Tube type | 24mm
Cockpit
Stem
BMC RSM 01
Handlebar
BMC HB D4 03, 0, 6 | Alloy 6061 | 135mm drop, 70mm reach, 6° flare
Seat
Saddle
Velo VL-1205 BMC
Seatpost
Trackmachine Carbon Airfoil Seatpost
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.241 mm | 1.306 mm | 1.363 mm |
| Bottom Bracket Height | 286 mm | 278 mm | 278 mm |
| Front Center | 577 mm | 592 mm | 616 mm |
| Rake | 43 mm | 43 mm | 43 mm |
| Trail | 58 mm | 58 mm | 58 mm |
| Stack | 490 mm | 525 mm | 563 mm |
| Reach | 395 mm | 402 mm | 413 mm |
| Top Tube Length | 540 mm | 558 mm | 580 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 520 mm | 550 mm | 585 mm |
| Head Tube Angle | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 110 mm | 138 mm | 178 mm |
| Chainstay Length | 390 mm | 390 mm | 390 mm |
| Wheelbase | 956 mm | 975 mm | 999 mm |
| Bottom Bracket Drop | 50 mm | 58 mm | 58 mm |
| Standover Height | 749 mm | 780 mm | 807 mm |
| Wheels | 700 | 700 | 700 |
| Rider Max Height | 173 cm | 185 cm | cm |
