Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID SL Select
-
Groupset X01 Eagle, GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 172cm
MD
170cm - 180cm
LG
178cm - 189cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Twostroke 01 Premium Carbon with Tuned Compliance Concept XC | Fully Guided Internal Cable Routing | PF92 Bottom Bracket | Post Mount Disc | 12x148mm Boost Thru-Axle
Suspension Fork
Rock Shox SID SL Select 3P, 100 mm - TwistLoc Remote Lockout
Drivetrain
Rear Derailleur
SRAM X01 Eagle
Shift Levers
SRAM GX Eagle Trigger
Cassette
SRAM CS-XG-1275-B1 10-52T
Crank
SRAM X1 Eagle DUB 34T
Bottom Bracket
BB86/BB92, press-fit
Chain
SRAM GX Eagle
Wheels
Rims
DT Swiss XR 1700 Wheelset, 25mm Inner Width
Tires
Vittoria Barzo 2.25" Tubeless
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
BMC MSM01
Handlebar
BMC MFB01 Carbon 760mm
Seat
Saddle
Fizik Antares R7
Seatpost
Twostroke 01 Premium Carbon D-Shaped Seatpost | 0mm Offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.392 mm | 1.344 mm | 1.308 mm | 1.285 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 694 mm | 720 mm | 744 mm | 770 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 109 mm | 109 mm | 109 mm | 109 mm |
| Stack | 588 mm | 598 mm | 608 mm | 623 mm |
| Reach | 422.5 mm | 445 mm | 465 mm | 485 mm |
| Top Tube Length | 597 mm | 618 mm | 638 mm | 658 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 415 mm | 440 mm | 470 mm | 510 mm |
| Head Tube Angle | 67 ° | 67 ° | 67 ° | 67 ° |
| Head Tube Length | 83 mm | 93.5 mm | 106 mm | 121 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1112 mm | 1135 mm | 1161 mm | 1185 mm |
| Bottom Bracket Drop | 64 mm | 64 mm | 64 mm | 64 mm |
| Standover Height | 725 mm | 730 mm | 735 mm | 750 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 162 cm | 170 cm | 178 cm | 187 cm |
| Rider Max Height | 172 cm | 180 cm | 189 cm | cm |
