BMC URS 01 ONE 2026
2026 Road
Estimate price |
9,306$
Weight | 9.1 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset X0 Eagle Transmission, Force -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes SRAM Force Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 170cm
MD
168cm - 178cm
LG
176cm - 189cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
URS 01 Premium Carbon with Micro Travel Technology | Gravel+ Geometry | ICS Technology | Integrated Storage | Fender and Rack Mounts | Flat Mount Disc | 12 x 142mm Thru-Axle | UDH Droput
Suspension Fork
URS 01 Premium Carbon with Tuned Compliance Concept Gravel | ICS Technology Integrated BRake & Hub Dynamo Routing | Cargo Mounts | Fender and Rack Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
Drivetrain
Rear Derailleur
SRAM X0 Eagle Transmission
Shift Levers
SRAM Force AXS (ED-FRC-E1)
Cassette
SRAM X0 Eagle Transmission XS-1295
Crank
SRAM Force AXS Wide (FC-FRC-1WP-E1)
Bottom Bracket
SRAM Press Fit DUB
Chain
SRAM X0 Eagle Transmission Flattop
Wheels
Rims
CG 35 SL Carbon | Tubeless Ready | 35mm
Tires
WTB Raddler | 44mm
Brakes
Brakes
SRAM Force AXS (ED-FRC-E1)
Cockpit
Stem
ICS MTT x Redshift Suspension Stem | Integrated Cockpit System Technology
Handlebar
Easton EC70 AX Carbon | 120mm drop, 80mm reach, 16° flare
Seat
Saddle
WTB Gravelier Titanium | Medium
Seatpost
URS 01 Premium Carbon D-Shaped Seatpost | 0mm Offset | D-Fender Compatible
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.436 mm | 1.4 mm | 1.415 mm | 1.452 mm | 1.488 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 273 mm | 273 mm | 273 mm |
| Front Center | 633 mm | 643 mm | 651 mm | 672 mm | 693 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm |
| Trail | 84 mm | 84 mm | 86 mm | 86 mm | 86 mm |
| Stack | 560 mm | 560 mm | 580 mm | 610 mm | 640 mm |
| Reach | 390 mm | 400 mm | 410 mm | 420 mm | 430 mm |
| Top Tube Length | 545 mm | 555 mm | 571 mm | 589 mm | 607 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 430 mm | 445 mm | 475 mm | 505 mm | 540 mm |
| Head Tube Angle | 69 ° | 69 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 133 mm | 133 mm | 140 mm | 172 mm | 204 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1052 mm | 1062 mm | 1070 mm | 1091 mm | 1112 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 76 mm | 76 mm | 76 mm |
| Standover Height | 727 mm | 735 mm | 758 mm | 778 mm | 795 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Max Height | 167 cm | 170 cm | 178 cm | 189 cm | cm |
