Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Suspension Rigid -
Brakes Tektro Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Lightweight Triple butted, smooth weld aluminium
Suspension Fork
1" Triple Butted, smooth weld aluminium lowers with Chromo Steerer
Drivetrain
Cassette
14 Tooth Sprocket
Crank
Prowheel 25 Tooth - 102mm crank and double chainguard
Bottom Bracket
FSA. - BB-7420ST
Chain
KMC
Pedals
Wellgo 9/16"
Wheels
Front Hub
Lightweight Alloy with Hex bolt fastening
Rear Hub
Lightweight Alloy with Hex bolt fastening
Rims
Double Wall Alloy
Tires
Vee Rubber, Speedster 16" x 1.5"
Brakes
Brakes
Front: TEKTRO J310 mini V-Brake, Rear: TEKTRO J310 mini V-Brake
Brake Levers
TEKTRO, JL 350 short reach
Cockpit
Stem
Boardman JNR 1-Piece Alloy
Handlebar
Boardman JNR 1-Piece Alloy - 460mm wide
Headset
Semi-Inegrated NECO H124 1" Aheadset
Seat
Saddle
Boardman JNR
Seatpost
Boardman JNR Alloy 25.4mm x 250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 12" | 16" | 20" | 24" | 26" | 26" |
|---|---|---|---|---|---|---|
| Wheels | 16" | 16" | 16" | 16" | 16" | 16" |
