Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Claris -
Suspension Rigid -
Drivetrain 1 × 8 -
Brakes Tektro Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Lightweight Triple butted, smooth weld aluminium
Suspension Fork
1" Triple Butted, smooth weld aluminium lowers with Chromo Steerer
Drivetrain
Rear Derailleur
Shimano RD-R2000 GS 8 Speed
Shift Levers
Microshift R480 8-Speed
Cassette
Shimano CS-HG 8 Speed 11-34 Tooth
Crank
Prowheel 32 Tooth - 140mm crank and double chainguard
Bottom Bracket
FSA. - BB-7420ST
Chain
KMC Z8.3
Pedals
Wellgo 9/16"
Wheels
Front Hub
Formula Alloy QR
Rear Hub
Formula Alloy QR
Rims
Double Wall Alloy
Tires
Vee Rubber, Speedster 26 x 1.5"
Brakes
Brakes
Front: TEKTRO Mira MD-C400 Mechanical Disc Brake - 160 mm Rotor, Rear: TEKTRO Mira MD-C400 Mechanical Disc Brake - 160 mm Rotor
Brake Levers
Microshift SB-R400 / R480 8-Speed
Cockpit
Stem
Boardman JNR Alloy 70mm / -7 degree rise
Handlebar
Boardman JNR Alloy - 25.4mm - 360 wide with 120mm drop
Headset
Semi-Inegrated NECO H124 1" Aheadset
Seat
Saddle
Boardman JNR
Seatpost
Boardman JNR Alloy 25.4mm x 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 12" | 16" | 20" | 24" | 26" | 26" |
|---|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" |
