Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Groupset GX Eagle, Truvativ Descendant -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
4130 double butted crmo, TA,rack / fender mounts, Boost spacing,stealth dropper ready, 73 mm BSA BB shell*
Suspension Fork
BOMBTRACK BPC full carbon, TA, 1.1/2" - 1.1/8", triple cage mounts,internal hub dynamo cable routing
Drivetrain
Rear Derailleur
SRAM GX EAGLE, clutch, long cage
Front Derailleur
-
Shift Levers
SRAM GX-EAGLE 12-speed trigger shifter
Cassette
SRAM XG-1275 EAGLE 12-speed, 10-52T
Crank
SRAM DESCENDANT aluminium crank, Boost DUB, SRAM EAGLE X-SYNC 2, narrow-wide, 30T
Bottom Bracket
SRAM DUB BSA 73 mm
Chain
SRAM GX EAGLE chain, 1/2" x 11/128", 118L
Pedals
-
Wheels
Front Hub
Front: BOMBTRACK GRAD Boost sealed hub, 6-bolt disc, Rear: BOMBTRACK GRAD Boost sealed hub, XD driver, 6-bolt disc
Rear Hub
Front: BOMBTRACK GRAD Boost sealed hub, 6-bolt disc, Rear: BOMBTRACK GRAD Boost sealed hub, XD driver, 6-bolt disc
Rims
Front: WTB ST i45 double wall, TCS 2.0, 32h, Rear: WTB ST i40 double wall, TCS 2.0, 32h
Tires
Front: WTB RANGER TCS TOUGH / FAST ROLLING 29" x 3.0",tubeless ready, Rear: WTB RANGER TCS TOUGH / FAST ROLLING 29" x 3.0",tubeless ready
Brakes
Brakes
MAGURA TRAIL SPORT 4 piston front, 2 piston rear with 180 mm rotors
Cockpit
Stem
BOMBTRACK TRAMP forged aluminium stem, 3°
Handlebar
JONES H-BAR LOOP 710 travel bar, 31.8 mm, 710 mm
Grips
BOMBTRACK SHIFT 170 mm grips
Headset
Sealed semi integrated / external aheadset, 1.1/2" - 1.1/8"
Seat
Saddle
BOMBTRACK ORIGIN saddle
Seatpost
BOMBTRACK YEW aluminium seatpost, 30.9 mm x 400 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.51 mm | 1.48 mm | 1.42 mm |
| Front Center | 670 mm | 694 mm | 718 mm | 747 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 97 mm | 97 mm | 97 mm | 97 mm |
| Stack | 627 mm | 636 mm | 650 | 659 mm |
| Reach | 401 mm | 421 mm | 440 mm | 465 mm |
| Top Tube Length | 579 mm | 604 mm | 628 mm | 656 mm |
| Seat Tube Angle | 74 ° | 73.7 ° | 73.7 ° | 73.7 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 110 mm | 125 mm | 135 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1117 mm | 1141 mm | 1166 mm | 1194 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 781 mm | 808 mm | 839 mm | 866 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Beyond+ ADV is part of the Bombtrack Beyondplus model. 7 bikes variations carry this model name so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Touring bikes
If you want an acceptable Touring bike you should know that the average price is 1007$. However, even if your budget is less than the average, you might still be able to get a top-quality Touring bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for Touring bikes
On a deeper look, we notice that the average weight of a Touring bike is 13.35 kg (29.43 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Bombtrack Beyond+ ADV it’s weighing 13.7 kg (30.2 lbs). At this weight, is slightly heavier than average. In other words, this model is 2.62% heavier than the average Touring bike.
Overview of components
Fork material
Beyond+ ADV has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on Beyond+ ADV are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Bombtrack Beyond+ ADV is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Bombtrack Beyond+ ADV bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
