Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 130mm -
Fork RockShox 35 Gold RL
-
Groupset XT -
Suspension Hardtail -
Motor Shimano 600W 85Nm mid-drive -
Battery Shimano BT-EN805 fully integrated battery, 504 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6 hydro-formed Aluminium, TA, rack / fender mounts, Boost spacing, stealth dropper ready, Shimano EP8 mid engine mount, UDH derailleur hanger,
Suspension Fork
RockShox 35 Gold RL suspension fork, 130 mm travel, 1.1/2" - 1.1/8"
Drivetrain
Rear Derailleur
Shimano Deore XT RD-M8100-SGS, clutch
Front Derailleur
-
Shift Levers
Shimano Deore XT SL-M8100-IR 1 x 12
Cassette
Shimano SLX CS-M7100-12, 12-speed, 10 - 51 T
Crank
Shimano Deore XT FC-EM600 forged aluminium crank
Bottom Bracket
-
Chain
Shimano SLX CN-M7100 chain, 1/2'' x 11/128'', 124L
Pedals
-
Wheels
Front Hub
Seido Boost sealed hub, centerlock disc
Rear Hub
Seido Grad sealed hub, Microspline, steel axle, centerlock disc
Rims
Front: WTB ST i30 double wall, TCS 2.0, 32h, Rear: WTB ST i30 double wall, TCS 2.0, 32h
Tires
Front: Kenda Hellcat Pro AEC 29'' x 2.4" TLR, tubeless ready, Rear: Kenda Hellcat Pro AEC 27.5'' x 2.6" TLR, tubeless ready
Brakes
Brakes
Shimano SLX BR-M7100 post mount hydraulic disc brake
Cockpit
Stem
Seido Drift aluminium stem, 35 mm clamping diameter
Handlebar
Bombtrack Illusion flat bar, aluminium, 35 mm clamping diameter
Grips
Bombtrack Return 135 mm lock on grips
Headset
Sealed integrated aheadset, 1.1/2'' - 1.1/8''
Seat
Saddle
Seido Origin saddle
Seatpost
KS E20i dropper seatpost, 30.9 mm, 150 mm travel, 474 mm length
Motor & Battery
Motor
Shimano DU-EP801 mid-drive engine
Battery
Shimano BT-EN805 fully integrated battery, 504 Wh
Charger
Shimano EC-E8004-1
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.388 mm | 1.341 mm | 1.318 mm | 1.283 mm |
| Front Center | 734 mm | 759 mm | 778 mm | 802 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 118 mm | 118 mm | 118 mm | 118 mm |
| Stack | 608 mm | 617 mm | 626 mm | 635 mm |
| Reach | 438 mm | 460 mm | 475 mm | 495 mm |
| Top Tube Length | 601 mm | 625 mm | 643 mm | 665 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 390 mm | 430 mm | 460 mm | 500 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1169 mm | 1195 mm | 1214 mm | 1238 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 780 mm | 789 mm | 808 mm | 832 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
