Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset Rival XPLR AXS, Rival AXS -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Columbus Cromor double butted, TA, rack / fender mounts, internal light cable routing, rear light mount, 85.5 mm T47 BB shell
Suspension Fork
Seido MGV full carbon, TA, 1.1/2'' - 1.1/8'', fender / triple cage mounts, 180 mm max rotor size, lowrider rack compatible, internal hub dynamo cable routing
Drivetrain
Rear Derailleur
SRAM Rival XPLR eTap AXS, clutch, medium cage
Front Derailleur
-
Shift Levers
SRAM Rival eTap AXS double tap 1 x 12
Cassette
SRAM XPLR XG-1251 12-speed, 10 - 44 T
Crank
SRAM Rival Wide, DUB spindle
Bottom Bracket
SRAM DUB T47 85.5 mm
Chain
SRAM Rival, flattop, 1/2'' x 11/128'', 112L
Pedals
-
Wheels
Front Hub
Bombtrack Tau sealed hub, 6-bolt disc
Rear Hub
Bombtrack Tau sealed hub, XD driver, 6-bolt disc
Rims
WTB ST Light i25 double wall, TCS 2.0, 32h
Tires
Front: WTB Ranger TCS Light / Fast Rolling 27.5'' x 2.0'', tubeless ready, Rear: WTB Ranger TCS Light / Fast Rolling 27.5'' x 2.0'', tubeless ready
Brakes
Brakes
SRAM Rival flat mount hydraulic disc brakes
Cockpit
Stem
Seido Chase forged aluminium stem, 0°
Handlebar
Bombtrack Beaufort drop bar, 31.8 mm, 16° flare
Grips
Bombtrack Escape bar tape
Headset
Sealed external aheadset, 1.1/2'' - 1.1/8''
Seat
Saddle
Bombtrack Dart saddle
Seatpost
Bombtrack Yew aluminium seatpost, 27.2 mm x 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.564 mm | 1.556 mm | 1.569 mm | 1.566 mm |
| Front Center | 588 mm | 603 mm | 618 mm | 632 mm | 652 mm |
| Rake | 53 mm | 53 mm | 53 mm | 53 mm | 53 mm |
| Trail | 64 mm | 64 mm | 61 mm | 60 mm | 60 mm |
| Stack | 558 mm | 577 mm | 593 mm | 612 mm | 631 mm |
| Reach | 360 mm | 369 mm | 381 mm | 390 mm | 403 mm |
| Top Tube Length | 520 mm | 534 mm | 558 mm | 572 mm | 597 mm |
| Seat Tube Angle | 73.9 ° | 73.9 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 460 mm | 500 mm | 530 mm | 570 mm | 600 mm |
| Head Tube Angle | 70.9 ° | 70.9 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Head Tube Length | 110 mm | 130 mm | 150 mm | 170 mm | 190 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1003 mm | 1018 mm | 1034 mm | 1049 mm | 1068 mm |
| Bottom Bracket Drop | 71 mm | 71 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 753 mm | 782 mm | 805 mm | 834 mm | 857 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
