Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 650b -
Suspension Rigid -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
full 4130 crmo, double butted tubing, tapered head tube, sliding dropouts, 68 mm BSA shell
Suspension Fork
alloy TA disc fork, 1.1/2" - 1.1/8" tapered steerer, with fender / rack mounts
Drivetrain
Shift Levers
-
Cassette
GATES CARBON CDX 20T cog
Crank
GATES CARBON S150 CDN alloy crank, square taper, GATES CARBON S150 CDN 55T
Bottom Bracket
FSA, sealed square taper
Chain
GATES CARBON CDN 115T belt
Pedals
ECLAT SLASH flatpedal
Wheels
Front Hub
Front: BOMBTRACK TITLE-DISC sealed, 6-bolt disc hub, female axle, Rear: BOMBTRACK TITLE-DISC sealed hub, 11-speed, 6-bolt disc, female axle
Rear Hub
Front: BOMBTRACK TITLE-DISC sealed, 6-bolt disc hub, female axle, Rear: BOMBTRACK TITLE-DISC sealed hub, 11-speed, 6-bolt disc, female axle
Rims
Front: BOMBTRACK XCD21 double wall, i20, 28h, Rear: BOMBTRACK XCD21 double wall, i20, 28h
Tires
Front: WTB HORIZON tire, 650B x 47C, Rear: WTB HORIZON tire, 650B x 47C
Brakes
Brakes
SHIMANO BL-M200 post mount hydraulic disc brake with 160 mm rotors
Cockpit
Stem
BOMBTRACK ROAM forged alloy stem, -7°
Handlebar
BOMBTRACK TRAIL flat bar, 7050-T73 butted alloy, 31.8 mm, 5° rise, 8° backsweep
Grips
BOMBTRACK TAB 129 mm grips
Headset
FSA NO.21/12/44 sealed external aheadset, 1.1/2" - 1.1/8"
Seat
Saddle
BOMBTRACK COMP saddle
Seatpost
BOMBTRACK CEDAR alloy seatpost, 27.2 mm x 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.47 mm | 1.49 mm | 1.51 mm |
| Front Center | 611 mm | 627 mm | 638 mm | 656 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 70.2 mm | 68.2 mm | 65.1 mm | 64.9 mm |
| Stack | 553 mm | 573 mm | 594 mm | 609 mm |
| Reach | 378 mm | 389 mm | 398 mm | 403 mm |
| Top Tube Length | 542 mm | 559 mm | 580 mm | 603 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 500 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 70.2 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 190 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1023 mm | 1039 mm | 1050 mm | 1068 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 770 mm | 795 mm | 813 mm | 838 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Outlaw completes the Bombtrack Outlaw model. Bombtrack launched 5 bikes of this model so far.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for General Urban bikes
According to our calculations, the average cost of a General Urban bike that is reliable is 499$. However, even if your budget is less than the average, you might still be able to get a top-quality General Urban bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Average weight for General Urban bikes
General Urban bikes have an average weight of 13.11 kg (28.9 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Outlaw weighs 10.5 kg (23.15 lbs) and is much lighter than the average. In short, the average General Urban bike weight is 24.86% higher than this one.
Outlaw components
Fork material
The fork is made out of aluminum, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
The wheels on Outlaw are the aluminum type. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. Bombtrack Outlaw is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Bombtrack Outlaw bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
