Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 650b -
Suspension Rigid -
Drivetrain Belt Drive -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
full 4130 crmo, double butted tubing, tapered head tube, sliding dropouts, 68 mm BSA shell
Suspension Fork
aluminum QR disc fork, 1.1/2" - 1.1/8" tapered steerer, with fender / rack mounts, internal hub dynamo cable routing
Drivetrain
Shift Levers
-
Cassette
GATES CARBON CDX 20T cog
Crank
GATES CARBON S300 CDX aluminum crank, 24 mm spindle, GATES CARBON S300 CDX 55T
Bottom Bracket
BSA sealed BB, external cups, for 24 mm spindle
Chain
GATES CARBON CDN 115T belt
Pedals
ECLAT SLASH flatpedal
Wheels
Front Hub
Front: BOMBTRACK TITLE-DISC sealed, 6-bolt disc hub, female axle, Rear: BOMBTRACK TITLE-DISC sealed hub, 11-speed, 6-bolt disc, female axle
Rear Hub
Front: BOMBTRACK TITLE-DISC sealed, 6-bolt disc hub, female axle, Rear: BOMBTRACK TITLE-DISC sealed hub, 11-speed, 6-bolt disc, female axle
Rims
Front: BOMBTRACK TX20 double wall, i19, 28h, Rear: BOMBTRACK TX20 double wall, i19, 28h
Tires
Front: WTB HORIZON tire, 650B x 47C, Rear: WTB HORIZON tire, 650B x 47C
Brakes
Brakes
SHIMANO BL-M200 post mount hydraulic disc brake with 160 mm rotors
Cockpit
Stem
BOMBTRACK ROAM forged aluminum stem, -7°
Handlebar
BOMBTRACK Origin flat bar, 31.8 mm, 8° backsweep
Grips
BOMBTRACK TAB 129 mm grips
Headset
FSA NO.21/12/44 sealed external aheadset, 1.1/2" - 1.1/8"
Seat
Saddle
BOMBTRACK COMP saddle
Seatpost
BOMBTRACK CEDAR aluminum seatpost, 27.2 mm x 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.48 mm | 1.5 mm | 1.52 mm |
| Front Center | 611 mm | 626 mm | 638 mm | 655 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 68.9 mm | 67 mm | 63.8 mm | 63.8 mm |
| Stack | 556 mm | 576 mm | 597 mm | 620 mm |
| Reach | 377 mm | 388 mm | 397 mm | 407 mm |
| Top Tube Length | 542 mm | 559 mm | 580 mm | 603 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 500 mm | 530 mm | 550 mm | 580 mm |
| Head Tube Angle | 70.2 ° | 70.5 ° | 71 ° | 71 ° |
| Head Tube Length | 125 mm | 145 mm | 165 mm | 190 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1023 mm | 1039 mm | 1050 mm | 1068 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 771 mm | 787 mm | 806 mm | 831 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Outlaw completes the Bombtrack Outlaw model. There are 5 bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
General Urban bikes average price
If you want an acceptable General Urban bike you should know that the average price is 499$. However, you could also get a good General Urban bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Outlaw components
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
The Outlaw 2020 bike is equipped with aluminum wheels when leaving the factory. After 700c wheels, 650b is the second most popular choice for road bikes. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Bombtrack Outlaw has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Bombtrack Outlaw bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
