Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Nexus -
Suspension Rigid -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Breezer custom-butted 6061 aluminum w/ split adjustable dropout
Suspension Fork
Breezer 6061 aluminum
Drivetrain
Shift Levers
Shimano Nexus 7 Revo-Shift, 7-speed
Cassette
C-Drive 33T
Crank
C-Drive Junior+, 64T
Bottom Bracket
VP sealed cartridge bearing
Chain
C-Drive Belt, 1200 x 11mm
Pedals
Wellgo resin platform
Wheels
Rims
Alex MD19, Stainless Spokes, Shimano Nexus 7-speed centerlock rear hub, 32H
Tires
Continental Contact Plus, 47-507, reflex
Brakes
Brakes
Tektro HD-J285, 160mm rotors
Brake Levers
Tektro, 2-finger
Cockpit
Stem
Alloy, 31.8mm, 40mm
Handlebar
Alloy flat bar
Grips
Single density kraton
Headset
FSA NO.10, 1 1/8", sealed bearing
Seat
Saddle
DDK F24, chromoly rails
Seatpost
Breezer Aluminum, 27.2mm
Fit data
Geometry
