Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 110mm -
Fork RockShox Judy Gold RL
-
Groupset CUES -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon
Suspension Fork
RockShox JUDY Gold RL R
Drivetrain
Rear Derailleur
SHIMANO Cues RD-U6000
Shift Levers
SHIMANO Cues SL-U6000
Cassette
SHIMANO CS-LG400-11 11-50T
Crank
SHIMANO Cues FC-U6000 32T
Chain
SHIMANO Linkglide CN-LG500
Wheels
Front Hub
SHIMANO DEORE HB-TC50015B
Rear Hub
SHIMANO DEORE FH-TC500-HM-B Boost
Rims
RYDE XC-21S Tubeless ready
Tires
SCHWALBE Smart Sam K-Guard
Brakes
Brakes
hydraulic disc brake
Brake Levers
SHIMANO BR-UR300
Cockpit
Stem
Rumble Altimate
Handlebar
RUMBLE Altimate 35 Riser
Headset
ACROS 320.52.569 IS52/28,6/ICR - ZS56/40/IPS
Seat
Saddle
BULLS Sportive Ergo
Seatpost
RUMBLE Pylonen 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.451 mm | 1.383 mm | 1.366 mm | 1.36 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 688 mm | 713 mm | 729 mm | 757 mm |
| Rake | 45 mm | 44 mm | 44 mm | 44 mm |
| Trail | 103 mm | 104 mm | 104 mm | 104 mm |
| Stack | 605 mm | 610 mm | 619 mm | 642 mm |
| Reach | 417 mm | 441 mm | 453 mm | 472 mm |
| Top Tube Length | 585 mm | 610 mm | 625 mm | 650 |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 410 mm | 440 mm | 480 mm | 520 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 135 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1111 mm | 1136 mm | 1152 mm | 1180 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
