Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 110mm -
Fork RockShox Judy Gold RL
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
RockShox Judy Gold RL
Drivetrain
Rear Derailleur
SHIMANO Deore RD-M6100 shadow+
Shift Levers
SHIMANO Deore SL-M6100, rapidfire+
Cassette
SHIMANO Deore CS-M6100-12 10-51T
Crank
SHIMANO FC-MT511 32T
Chain
SHIMANO Deore CN-M6100-12
Wheels
Front Hub
SHIMANO HB-TC500-15-B
Rear Hub
SHIMANO FH-QC500-MS
Rims
BULLS DDM-22
Tires
SCHWALBE Racing Ray / Racing Ralph Performance
Brakes
Brakes
hydraulic disc brake
Brake Levers
SHIMANO BR-UR300
Cockpit
Stem
Bulls MTB Stem CCS Slot Mount ready
Handlebar
BULLS Sport-SL
Headset
FSA No.57SC
Seat
Saddle
Bulls MTB Sport
Seatpost
BULLS Aluminium 31.6 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.463 mm | 1.379 mm | 1.347 mm | 1.359 mm | 1.424 mm |
| Bottom Bracket Height | 309 mm | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 680 mm | 702 mm | 723 mm | 745 mm | 765 mm |
| Rake | 44 mm | 45 mm | 45 mm | 45 mm | 41 mm |
| Trail | 97 mm | 96 mm | 96 mm | 96 mm | 100 mm |
| Stack | 613 mm | 608 mm | 617 mm | 640 mm | 682 mm |
| Reach | 419 mm | 441 mm | 458 mm | 471 mm | 479 mm |
| Top Tube Length | 595 mm | 615 mm | 635 mm | 655 mm | 675 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 440 mm | 490 mm | 530 mm | 600 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 135 mm | 180 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1107 mm | 1130 mm | 1151 mm | 1173 mm | 1193 mm |
| Bottom Bracket Drop | 65 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
