Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Claris -
Suspension Rigid -
Drivetrain 2 × 8 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
Machete Carbon, internal cable routing, 12mm thru axle
Drivetrain
Rear Derailleur
SHIMANO Claris RD-R2000
Front Derailleur
SHIMANO Claris FD-R2000
Shift Levers
SHIMANO Claris ST-R2000
Cassette
SHIMANO CS-HG50-8, 8-PCS, 11-34T
Crank
SHIMANO Claris FC-RS200 46/34T
Chain
KMC, HG-40
Wheels
Front Hub
FORMULA CL-512
Rear Hub
FORMULA DC-22RQR
Rims
BULLS DDM-22
Tires
VEE TIRE CO. Rail MPC
Brakes
Brakes
Mechanical disc brake
Cockpit
Stem
Bulls MTB Stem CCS Slot Mount ready
Handlebar
BULLS Gravel SL
Headset
FSA ORBIT C40ACB (NO.42/ACB)
Seat
Saddle
Bulls MTB Sport
Seatpost
Bulls Aluminium 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.509 mm | 1.509 mm | 1.538 mm | 1.531 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 607 mm | 630 mm | 650 | 674 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 73 mm | 73 mm | 73 mm | 73 mm |
| Stack | 575 mm | 599 mm | 626 mm | 649 mm |
| Reach | 381 mm | 397 mm | 407 mm | 424 mm |
| Top Tube Length | 546 mm | 569 mm | 587 mm | 610 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 450 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 135 mm | 160 mm | 189 mm | 213 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1042 mm | 1066 mm | 1086 mm | 1110 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
