Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 600, GRX 400 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
Machete Carbon, internal cable routing, 12mm thru axle
Drivetrain
Rear Derailleur
SHIMANO GRX RD-RX400
Front Derailleur
SHIMANO GRX FD-RX400
Shift Levers
SHIMANO Tiagra ST-4700
Cassette
SHIMANO CS-HG500-10 11-36T
Crank
SHIMANO GRX FC-RX600 46/30T
Chain
SHIMANO CN-HG54-10
Wheels
Front Hub
FORMULA CL-512
Rear Hub
FORMULA DC-22RQR
Rims
BULLS DDM-22
Tires
VEE TIRE CO. Rail MPC
Brakes
Brakes
Mechanical disc brake
Cockpit
Stem
Bulls MTB Stem CCS Slot Mount ready
Handlebar
BULLS Gravel SL
Headset
FSA ORBIT C40ACB (NO.42/ACB)
Seat
Saddle
Bulls MTB Sport
Seatpost
Bulls Aluminium 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.509 mm | 1.509 mm | 1.538 mm | 1.531 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 607 mm | 631 mm | 650 | 327 mm |
| Rake | 45 mm | 45 mm | 46 mm | mm |
| Trail | 73 mm | 73 mm | 72 mm | mm |
| Stack | 575 mm | 599 mm | 626 mm | 649 mm |
| Reach | 381 mm | 397 mm | 407 mm | 424 mm |
| Top Tube Length | 450 mm | 470 mm | 510 mm | 550 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 450 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 135 mm | 160 mm | 189 mm | 213 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1032 mm | 1056 mm | 1076 mm | mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
