Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork BULLS Lytro
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
BULLS Lytro 34 Air LOR, 1.8 Steerer, Boost
Drivetrain
Rear Derailleur
SHIMANO Cues RD-U6000
Shift Levers
SHIMANO Cues SL-U6000
Cassette
SHIMANO CUES CS-LG300-10 11-48T
Crank
SAMOX EC-53
Chain
SHIMANO Linkglide CN-LG500
Pedals
Bulls Iconic
Wheels
Front Hub
SHIMANO DEORE HB-TC50015B
Rear Hub
SHIMANO CUES FH-QC400 Boost
Rims
BULLS DDM-30
Tires
SCHWALBE Smart Sam K-Guard
Brakes
Brakes
hydraulic disc brake
Cockpit
Handlebar
Holistic Cockpit 10
Headset
FSA NO.72/55R 1.8” /CUP/CR
Seat
Saddle
BULLS Iconic SUV
Seatpost
RUMBLE Escalator, 34.9 mm / S/M/L 150mm, XL/XXL 170 mm + SL-MT500-L (with clamp)
Motor & Battery
Motor
Bosch Performance Line CX GEN5 (Smart System) 25/85 Nm
Charger
Bosch Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.547 mm | 1.543 mm | 1.503 mm | 1.448 mm | 1.483 mm |
| Front Center | 726 mm | 737 mm | 758 mm | 785 mm | 814 mm |
| Rake | 50 mm | 51 mm | 51 mm | 52 mm | 51 mm |
| Trail | 97 mm | 96 mm | 96 mm | 95 mm | 96 mm |
| Stack | 642 mm | 651 mm | 660 mm | 669 mm | 706 mm |
| Reach | 415 mm | 422 mm | 439 mm | 462 mm | 476 mm |
| Top Tube Length | 605 mm | 615 mm | 635 mm | 660 mm | 685 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 400 mm | 430 mm | 470 mm | 510 mm | 570 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 180 mm |
| Chainstay Length | 450 mm | 450 mm | 450 mm | 450 mm | 450 mm |
| Wheelbase | 1169 mm | 1181 mm | 1202 mm | 1229 mm | 1258 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
