BULLS SONIC AM 2 ABS 2025
2025 E-bike
Estimate price |
6,881$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 150mm -
Travel Rear 140mm -
Fork Suntour Zeron
-
Groupset XT, CUES -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon
Suspension Fork
SR SUNTOUR ZERON 36 1.8 Air 150 mm 29” ABS
Drivetrain
Rear Derailleur
SHIMANO DEORE XT RD-M8130 shadow+
Shift Levers
SHIMANO Cues SL-U6000
Cassette
SHIMANO DEORE CS-LG600-11 11-50T
Crank
SAMOX EC-53
Chain
SHIMANO Linkglide CN-LG500
Pedals
ZECURE MTB pedals
Wheels
Front Hub
SHIMANO ALTUS HB-TC500-B Boost
Rear Hub
SHIMANO DEORE FH-TC500-HM-B Boost
Rims
RADIALE MTB 30
Tires
SCHWALBE Magic Mary Performance black bronze
Brakes
Brakes
hydraulic disc brake
Cockpit
Stem
Rumble Altimate
Handlebar
RUMBLE Altimate
Headset
Acros AIF617 1.8” IS60/28.6 - ZS60/46 ICR
Seat
Saddle
SELLE ROYAL SRX
Seatpost
LIMOTEC Alpha Dropper Post
Motor & Battery
Motor
Bosch Performance Line CX GEN5 (Smart System) 25/85 Nm
Charger
Bosch Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.466 mm | 1.371 mm | 1.331 mm | 1.295 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 756 mm | 782 mm | 810 mm | 834 mm |
| Rake | 50 mm | 46 mm | 49 mm | 49 mm |
| Trail | 119 mm | 124 mm | 121 mm | 121 mm |
| Stack | 623 mm | 624 mm | 632 mm | 641 mm |
| Reach | 425 mm | 455 mm | 475 mm | 495 mm |
| Top Tube Length | 580 mm | 605 mm | 633 mm | 655 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 410 mm | 440 mm | 470 mm | 510 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 460 mm | 460 mm | 460 mm | 460 mm |
| Wheelbase | 1214 mm | 1240 mm | 1268 mm | 1292 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
