Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 170mm -
Travel Rear 160mm -
Fork RockShox Domain
-
Groupset XT -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon
Suspension Fork
RockShox Domain Gold R 1.8
Drivetrain
Rear Derailleur
SHIMANO DEORE XT RD-M8130 shadow+
Shift Levers
SHIMANO DEORE XT SL-M8130, rapidfire+, I-spec-EV
Cassette
SHIMANO DEORE CS-LG600-11 11-50T
Crank
SAMOX EC-53
Chain
SHIMANO Linkglide CN-LG500
Pedals
ZECURE MTB pedals
Wheels
Rims
MAVIC E-Deemax
Tires
SCHWALBE Magic Marry Performance/ Big Betty Performance
Brakes
Brakes
hydraulic disc brake
Cockpit
Stem
Rumble Altimate
Handlebar
RUMBLE Altimate
Headset
Acros AIF617 1.8” IS60/28.6 - ZS60/46 ICR
Seat
Saddle
SELLE ROYAL SRX
Seatpost
LIMOTEC Alpha Dropper Post
Motor & Battery
Motor
Bosch Performance Line CX GEN5 (Smart System) 25/85 Nm
Charger
Bosch Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.345 mm | 1.326 mm |
| Bottom Bracket Height | 343 mm | 343 mm |
| Front Center | 789 mm | 818 mm |
| Rake | 38 mm | 38 mm |
| Trail | 131 mm | 131 mm |
| Stack | 612 mm | 630 mm |
| Reach | 455 mm | 475 mm |
| Top Tube Length | 591 mm | 615 mm |
| Seat Tube Angle | 76 ° | 76 ° |
| Seat Tube Length | 440 mm | 480 mm |
| Head Tube Angle | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 120 mm |
| Chainstay Length | 445 mm | 445 mm |
| Wheelbase | 1234 mm | 1263 mm |
| Bottom Bracket Drop | 12 mm | 12 mm |
| Wheels | 27" | 27" |
