Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 170mm -
Travel Rear 160mm -
Fork RockShox ZEB
-
Groupset Eagle AXS, GX Eagle Transmission -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon
Suspension Fork
RockShox ZEB
Drivetrain
Rear Derailleur
SRAM GX Eagle AXS Transmission
Shift Levers
SRAM EC AXS Rocker
Cassette
SRAM Eagle 70 Transmission 10-52T
Crank
SRAM GX Eagle
Chain
SRAM Eagle GX
Pedals
ZECURE MTB pedals
Wheels
Rims
MAVIC E-Deemax
Tires
SCHWALBE Tacky Chan EVO / Big Betty EVO
Brakes
Brakes
hydraulic disc brake
Cockpit
Stem
Rumble Altimate Pro Carbon, width: 780mm, Backsweep: 9°
Handlebar
RUMBLE Altimate PRO Carbon
Headset
Acros AIF617 1.8” IS60/28.6 - ZS60/46 ICR
Seat
Saddle
Prologo Proxim Nembo
Seatpost
8PINS hydraulic dropper post
Motor & Battery
Motor
Bosch Performance Line CX GEN5 (Smart System) 25/85 Nm
Charger
Bosch Charger 4A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.345 mm | 1.326 mm |
| Bottom Bracket Height | 343 mm | 343 mm |
| Front Center | 789 mm | 818 mm |
| Rake | 38 mm | 38 mm |
| Trail | 131 mm | 131 mm |
| Stack | 612 mm | 630 mm |
| Reach | 455 mm | 475 mm |
| Top Tube Length | 591 mm | 615 mm |
| Seat Tube Angle | 76 ° | 76 ° |
| Seat Tube Length | 440 mm | 480 mm |
| Head Tube Angle | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 120 mm |
| Chainstay Length | 445 mm | 445 mm |
| Wheelbase | 1234 mm | 1263 mm |
| Bottom Bracket Drop | 12 mm | 12 mm |
| Wheels | 27" | 27" |
