Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Deore -
Suspension Rigid -
Motor Bafang 30Nm hub-drive -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 177cm
LG
175cm - 188cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminium
Suspension Fork
Grinder Aluminium Flatmount
Drivetrain
Rear Derailleur
SHIMANO Deore RD-M5120 shadow
Shift Levers
SHIMANO Deore SL-M4100
Cassette
SHIMANO Deore CS-M4100-10 11-46T
Crank
BULLS
Chain
KMC E10S
Pedals
Bulls Urban Pedals with Griptape
Wheels
Front Hub
FORMULA DC-20FQR
Rear Hub
FIT BAFANG H600 25/30 Nm
Rims
BULLS DDM-22
Tires
SCHWALBE G-ONE ALLROUND Perf, RaceGuard, TLE
Brakes
Brakes
hydraulic disc brake
Cockpit
Handlebar
Bulls Urban Comfort Unit
Headset
FSA ORBIT C40ACB (NO.42/ACB)
Seat
Saddle
BULLS Sportive Ergo
Seatpost
30.9 mm Aluminium
Motor & Battery
Motor
FIT BAFANG H600 25/30 Nm
Charger
FIT charger 3A, 48V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.414 mm | 1.462 mm | 1.486 mm |
| Front Center | 651 mm | 668 mm | 689 mm |
| Rake | 44 mm | 45 mm | 45 mm |
| Trail | 74 mm | 73 mm | 73 mm |
| Stack | 594 mm | 623 mm | 651 mm |
| Reach | 420 mm | 426 mm | 438 mm |
| Top Tube Length | 590 mm | 605 mm | 620 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 150 mm | 180 mm | 210 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1097 mm | 1114 mm | 1135 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 177 cm | 188 cm | 198 cm |
