Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork RockShox Recon Silver RL
-
Groupset NX -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alu 6061 27.5”, 148 Boost Thru Axle, Post-mount disc, 44/56 tapered headtube
Suspension Fork
RockShox FS-RECON SILVER-RL, 46 offset, 140mm travel, 15x110mm Boost Thru-axle
Drivetrain
Rear Derailleur
SRAM NX 11 Speed, Long cage
Shift Levers
SRAM NX 11 Speed
Cassette
Sunrace 11 speed 11-42T
Crank
Calibre 170mm crank, 32T Narrow-wide chainring, 104 BCD
Bottom Bracket
External 73mm BSA BB
Chain
KMC X-11
Pedals
Flat pedals
Wheels
Front Hub
Formula DC711, 32h, 6 bolt disc hub, 15x110mm TA
Rear Hub
Formula DCL348S, 32h, 6 bolt disc hub, 12x148mm TA
Rims
27.5”, 35mm wide, 32h, alu double wall, tubeless ready
Tires
Maxxis Rekon 27.5” x 2.6”
Brakes
Brakes
SRAM Level T
Cockpit
Stem
Calibre Trail, 31.8mm clamp, 45mm extension
Handlebar
Calibre Trail, Alloy 780mm wide, 20mm upsweep, 6°backsweep, 31.8mm clamp
Grips
Calibre Trail, Single lock-on, soft compound, integrated bar ends
Headset
Tapered, Semi-integrated, ZS44 / ZS56
Seat
Saddle
Calibre Trail, steel rails
Seatpost
30.9 KS Rage-i Dropper post, 125mm travel
Fit data
Geometry
