Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour
-
Groupset Shimano -
Suspension Hardtail -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 hydroformed alloy frame
Suspension Fork
Suntour XCE 100mm coil spring
Drivetrain
Rear Derailleur
Shimano
Front Derailleur
Shimano
Shift Levers
Shimano EZ fire
Cassette
Shimano 7-speed
Crank
Triple 24x34x42
Pedals
PVC platform pedals
Wheels
Rims
27.5" alloy 32 hole double wall
Tires
27.5” x 2.1”
Brakes
Brakes
Tektro cable disc brakes
Cockpit
Stem
Alloy 60mm, 6 degree rise, 31.8mm clamp
Handlebar
760mm wide, 12mm rise, 31.8mm clamp
Seat
Saddle
Calibre all rounder
Seatpost
Alloy 27.2mm x 300mm micro adjust
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Bottom Bracket Height | 322 mm | 322 mm | 322 mm |
| Top Tube Length | 606 mm | 626 mm | 649 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406 mm | 450 mm | 508 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm |
| Bottom Bracket Drop | 33 mm | 33 mm | 33 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
About this model
Rail belongs to the Calibre Rail model. Calibre released 3 bikes variations of this model so far.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Rail components
Fork
The fork installed on this bike is the SunTour model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
As for the wheels, Calibre Rail 2021, has a 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Rail has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Calibre Rail bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In conclusion, it won’t take much to find one that’s right for you.
