Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 163mm -
Travel Rear 163mm -
Fork Fox Factory Float 38
-
Suspension Full -
Brakes TRP Trail EVO Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Fox 38 Factory Grip 2 170mm, RockShox Zeb ULT Charger 3 A2 170mm
Rear Shock
Fox FACTORY Float X2 Air, RockShox Vivid ULT Coil
Drivetrain
Crank
Canfield All Mountain Cranks (165mm length)
Wheels
Rims
e*thirteen LG1+ Enduro
Tires
Maxxis DHF 2.5 & Maxxis Dissector 2.4
Brakes
Brakes
TRP Trail EVO w/203/180mm Rotors
Cockpit
Stem
Canfield Special Blend AM
Handlebar
e*thirteen Base 800mm
Seat
Saddle
SDG Canfield Limited Edition
Seatpost
SDG Tellis
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.494 mm | 1.422 mm | 1.356 mm | 1.298 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Center | 764 mm | 791 mm | 818 mm | 845 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 129 mm | 129 mm | 129 mm | 129 mm |
| Stack | 635 mm | 640 mm | 644 mm | 649 mm |
| Reach | 425 mm | 450 mm | 475 mm | 500 mm |
| Top Tube Length | 575 mm | 601 mm | 628 mm | 655 mm |
| Seat Tube Angle | 76.7 ° | 76.7 ° | 76.7 ° | 76.7 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 490 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1193 mm | 1221 mm | 1248 mm | 1275 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm | 28 mm |
| Standover Height | 702 mm | 739 mm | 770 mm | 782 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
