Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 170mm -
Travel Rear 163mm -
Fork Fox Factory Float 38
-
Groupset X01 -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Fox 38 Factory 170mm
Rear Shock
2024 Fox FLOAT X2 Factory
Drivetrain
Rear Derailleur
SRAM XO1
Shift Levers
SRAM XO1
Cassette
SRAM XO1 10-52t
Crank
Canfield AM
Wheels
Rims
Atomik AL 30
Tires
Maxxis DHF 2.5, Maxxis Dissector 2.4
Brakes
Brakes
TRP Trail Evo
Cockpit
Stem
Canfield
Handlebar
E.Thirteen Base 800mm
Seat
Saddle
Canfield SDG
Seatpost
SDG Tellis
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.494 mm | 1.422 mm | 1.356 mm | 1.298 mm |
| Bottom Bracket Height | 350 mm | 350 mm | 350 mm | 350 mm |
| Front Center | 764 mm | 791 mm | 818 mm | 845 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 129 mm | 129 mm | 129 mm | 129 mm |
| Stack | 635 mm | 640 mm | 644 mm | 649 mm |
| Reach | 425 mm | 450 mm | 475 mm | 500 mm |
| Top Tube Length | 575 mm | 601 mm | 628 mm | 655 mm |
| Seat Tube Angle | 76.7 ° | 76.7 ° | 76.7 ° | 76.7 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 490 mm |
| Head Tube Angle | 64.5 ° | 64.5 ° | 64.5 ° | 64.5 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1193 mm | 1221 mm | 1248 mm | 1275 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm | 28 mm |
| Standover Height | 702 mm | 739 mm | 770 mm | 782 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
